Design
Product colour: Black
Glass thickness: 3.7 mm
Front bezel colour: Black
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 98 W
Power consumption (off): 0.3 W
Power supply type: Internal
Power consumption (standby): 0.5 W
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): G
Energy efficiency scale: A to G
Operational conditions
Operating relative humidity (H-H): -20 - 60%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth (with stand): 72.8 mm
Height (with stand): 577.8 mm
Width (with stand): 989.6 mm
Weight (with stand): 13.7 kg
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Operating system installed: Android
Operating hours (hours/days): 24/7
Palm rejection: Yes
Operating system version: 14
Packaging data
Package height: 730 mm
Package weight: 17.6 kg
Package width: 1115 mm
Package depth: 144 mm
Packaging content
Quick start guide: Yes
Cables included: HDMI, RS-232, AC
Batteries included: Yes
Remote control included: Yes
Remote control batteries included: Yes
HDMI cable length: 1.8 m
Power cable length: 1.8 m
Thin Client
Processor cores: 4
Processor architecture: ARM Cortex-A73
Display
Response time: 6.5 ms
Display diagonal: 108 cm (42.5")
LED backlight: Yes
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Display resolution: 3840 x 2160 pixels
Display brightness (typical): 500 cd/m²
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Screen shape: Flat
Viewing angle, horizontal: 178°
Pixel pitch: 0.245 x 0.245 mm
Display number of colours: 1.07 billion colours
Panel type: VA
Viewable size, horizontal: 94.1 cm
Contrast ratio (typical): 4000:1
Display diagonal (metric): 108 cm
Viewable size, vertical: 52.9 cm
Display technology: LED
Touchscreen: Yes
Backlight type: Direct LED
Response time measurement type: GTG (Gray to Gray)
Touchscreen technology: Projected capacitive system
Surface hardness: 8
Anti-glare screen: Yes
NTSC coverage (typical): 72%
Display brightness: 420 cd/m²
Number of simultaneous touchpoints: 20
Multimedia
Number of speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ergonomics
Panel mounting interface: 300 x 300
Number of OSD languages: 8
On Screen Display (OSD) languages: Japanese, French, Polish, German, Dutch, English, Russian, Spanish
On Screen Display (OSD): Yes
VESA mounting: Yes
Ports & interfaces
HDCP: Yes
HDMI version: 1.4/2.0
DVI port: No
HDMI ports quantity: 2
USB version: 2.0
USB Power Delivery (USB PD): Yes
USB Power Delivery up to: 15 W
USB Type-C DisplayPort Alternate Mode: Yes
RS-232C: Yes
USB Touch port: Yes
HDCP version: 1.4/2.2
Certification: CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA, cTUVus
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Packaging content: Wall Mounting Bracket (VESA 300x300), Magnetic holding places for Touch pens (on sides in landscape)
Other features
Weight: 13.7 kg
Ethernet LAN (RJ-45) ports: 1
Height: 577.8 mm
Depth: 72.8 mm
Width: 989.6 mm
Placement supported: Indoor
Built-in processor: Yes
Compliance certificates: cTUVus, UKCA, RoHS, CE, CB, EAC, REACH, TÜV mark, WEEE
Touch method: stylus, finger
Brightness: 420 cd/m²
Active display area (W x H): 941.2 x 529.4 mm
Multi-touch: Yes
USB ports quantity: 2
Control panel: Power (long press for Quick Menu (source, volume +, volume -, brightness +, brightness -, Touch unlock)
Mean time between failures (MTBF): 50000 h
Positional accuracy: 2.5 mm
Sustainability
Sustainability certificates: ErP
