Technical details
Sustainability certificates: ErP
Compliance certificates: RoHS, CE, TÜV mark, cTUVus, CB, EAC, UKCA, WEEE, REACH
Design
Product colour: Black
Orientation: Horizontal/Vertical
VESA mounting: Yes
Screen shape: Flat
Product design: Kiosk design
Anti-glare screen: Yes
Bezel colour: Black
Panel mounting interface: 300 x 400 mm
Placement supported: Indoor
Power
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (standby): 0.5 W
Energy efficiency class (SDR): G
Energy efficiency scale: A to G
Power consumption (typical): 104 W
Energy efficiency class (HDR): Not available
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): -20 - 60%
Weight & dimensions
Depth: 42.3 mm
Width (with stand): 1258.2 mm
Display height: 728.8 mm
Weight: 26.8 kg
Width: 1258.2 mm
Height: 728.8 mm
Display weight: 26.8 kg
Weight (with stand): 26.8 kg
Height (with stand): 728.8 mm
Depth (with stand): 42.3 mm
Display depth: 42.3 mm
Display width: 1258.2 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
On Screen Display (OSD) languages: Finnish, English, Norwegian, Spanish, Swedish, Polish, Danish, German, Italian, Dutch, Russian, Czech, French
HDCP: Yes
Number of OSD languages: 8
On Screen Display (OSD): Yes
Operating hours (hours/days): 24/7
Purpose: Universal
Mean time between failures (MTBF): 50000 h
HDCP version: 1.4/2.2
Packaging data
Package height: 850 mm
Package width: 1400 mm
Package weight: 32.7 kg
Package depth: 164 mm
Packaging content
Cables included: HDMI, RS-232, AC
Remote control included: Yes
Stylus pen: Yes
Number of stylus pens: 2
Batteries included: Yes
Display
HD type: 4K Ultra HD
Response time: 6.5 ms
Viewing angle, horizontal: 178°
LED backlight: Yes
Native aspect ratio: 16:9
Display diagonal: 138.7 cm (54.6")
Display resolution: 3840 x 2160 pixels
Glass thickness: 3.7 mm
Panel type: VA
Contrast ratio (typical): 4000:1
Touchscreen technology: Projected capacitive system
LED backlighting type: Direct-LED
Viewing angle, vertical: 178°
Display diagonal (metric): 139 cm
Touchscreen: Yes
Surface hardness: 8
Display brightness: 450 cd/m²
Multi-touch: Yes
Display technology: LED
Display number of colours: 1.07 billion colours
Active display area (W x H): 1209.6 x 680.4 mm
Horizontal scan range: 28 - 160 kHz
Number of simultaneous touchpoints: 20
Pixel pitch: 0.315 x 0.315 mm
Audio
RMS rated power: 20 W
Built-in speaker(s): Yes
Number of built-in speakers: 2
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
HDMI version: 1.4/2.0
RS-232C: Yes
USB Power Delivery (USB PD): Yes
HDMI ports quantity: 2
USB ports quantity: 2
USB Type-C DisplayPort Alternate Mode: Yes
USB port: Yes
USB version: 2.0
USB Power Delivery up to: 15 W
DVI port: No
Remote (IR) output: 1
Remote (IR) input: 1
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Quick start guide: Yes
Power supply type: Internal
Viewable size, horizontal: 121 cm
Viewable size, vertical: 68 cm
Brightness: 450 cd/m²
Backlight type: Direct LED
Computer system
Processor cores: 4
Operating system installed: Android
Internal memory: 4 GB
On-board graphics card model: ARM Mali-G51
Internal storage capacity: 32 GB
Operating system version: 14
Processor manufacturer: ARM
Processor architecture: ARM Cortex-A73
Built-in processor: Yes
