Technical details
Compliance certificates: cTUVus, REACH, UKCA, CB, EAC, TÜV mark, RoHS, CE, WEEE
Sustainability certificates: ErP
Design
Screen shape: Flat
Panel mounting interface: 400 x 400
Placement supported: Indoor
Product design: Kiosk design
VESA mounting: Yes
Product colour: Black
Bezel colour: Black
Orientation: Horizontal/Vertical
Anti-glare screen: Yes
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 118 W
AC input frequency: 50/60 Hz
Power consumption (standby): 0.5 W
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): G
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): -20 - 60%
Weight & dimensions
Depth (with stand): 42.8 mm
Width (with stand): 1447.3 mm
Weight: 38.5 kg
Height (with stand): 852.3 mm
Height: 852.3 mm
Depth: 42.8 mm
Width: 1447.3 mm
Display height: 852.3 mm
Display depth: 42.8 mm
Weight (with stand): 38.5 kg
Display weight: 38.5 kg
Display width: 1447.3 mm
Network
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Wi-Fi: Yes
Performance
HDCP: Yes
Purpose: Universal
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Polish, German, Italian, Dutch, Swedish, Russian, Czech, Finnish, Danish, Spanish, English, Norwegian, French
Operating hours (hours/days): 24/7
Mean time between failures (MTBF): 50000 h
Number of OSD languages: 8
HDCP version: 1.4/2.2
Packaging data
Package width: 1645 mm
Package weight: 47.3 kg
Package height: 1050 mm
Package depth: 192 mm
Packaging content
Cables included: AC, HDMI, RS-232
Batteries included: Yes
Remote control included: Yes
Number of stylus pens: 2
Stylus pen: Yes
Display
Display diagonal: 163.8 cm (64.5")
Response time: 6.5 ms
Display technology: LED
LED backlight: Yes
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Panel type: VA
Touchscreen: Yes
Display diagonal (metric): 164 cm
Display resolution: 3840 x 2160 pixels
Display number of colours: 1.07 billion colours
Pixel pitch: 0.372 x 0.372 mm
Native aspect ratio: 16:9
Contrast ratio (typical): 4000:1
HD type: 4K Ultra HD
Viewing angle, horizontal: 178°
Surface hardness: 8
Active display area (W x H): 1428.5 x 803.5 mm
Touchscreen technology: Projected capacitive system
LED backlighting type: Edge-LED
Glass thickness: 3.7 mm
Multi-touch: Yes
Display brightness: 420 cd/m²
Number of simultaneous touchpoints: 20
Audio
RMS rated power: 20 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
HDMI version: 1.4/2.0
DVI port: No
Ethernet LAN (RJ-45) ports: 1
USB port: Yes
HDMI ports quantity: 2
USB version: 2.0
USB Power Delivery up to: 15 W
RS-232C: Yes
USB Type-C DisplayPort Alternate Mode: Yes
Remote (IR) output: 1
USB Power Delivery (USB PD): Yes
USB ports quantity: 2
Remote (IR) input: 1
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Quick start guide: Yes
Power supply type: Internal
Brightness: 420 cd/m²
Viewable size, vertical: 80.3 cm
Viewable size, horizontal: 142.8 cm
Computer system
Internal memory: 4 GB
On-board graphics card model: ARM Mali-G51
Processor cores: 4
Processor manufacturer: ARM
Built-in processor: Yes
Operating system installed: Android
Processor architecture: ARM Cortex-A73
Internal storage capacity: 32 GB
Operating system version: 14
