Technical details
Playback media: Y
Compliance certificates: CB, EAC, REACH, TÜV mark, WEEE, RoHS, CE
OPS slot: 1
Warranty period: 5 year(s)
Audio in (mini jack): Yes
Sustainability certificates: ErP
Design
Product colour: Black
Placement supported: Indoor
VESA mounting: Yes
Panel mounting interface: 400 x 400 mm
Product design: Interactive flat panel
Anti-glare screen: Yes
Orientation: Horizontal
Bezel colour: Black
Positioning accuracy: 1 mm
Power
Power consumption (off): 0.3 W
Power consumption (typical): 126 W
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (standby): 0.4 W
Energy efficiency class (SDR): G
Energy efficiency scale: A to G
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 126 kWh
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Depth: 117.5 mm
Weight: 28.7 kg
Width: 1267 mm
Height: 765.5 mm
Display weight: 28.7 kg
Display depth: 117.5 mm
Display width: 1267 mm
Display height: 765.5 mm
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 1000 Mbit/s
Wi-Fi: Yes
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
Performance
HDCP: Yes
Purpose: Education
On Screen Display (OSD): Yes
Number of OSD languages: 13
On Screen Display (OSD) languages: Danish, German, Ukrainian, Finnish, French, Swedish, Hungarian, Lithuanian, Russian, Czech, Estonian, Italian, Dutch, Polish, English, Norwegian, Spanish, LAT, CAT
Mean time between failures (MTBF): 50000 h
Operating hours (hours/days): 24/7
HDCP version: 2.2
Packaging content
Remote control included: Yes
Cables included: AC, HDMI, USB
Stylus pen: Yes
Number of stylus pens: 4
Display
Panel type: IPS
Viewing angle, vertical: 178°
Display diagonal (metric): 138.8 cm
Response time: 8 ms
Horizontal scan range: 30 - 135 kHz
Touchscreen: Yes
Native aspect ratio: 16:9
Display resolution: 3840 x 2160 pixels
Display number of colours: 1.07 billion colours
Pixel pitch: 0.315 x 0.315 mm
Display diagonal: 138.7 cm (54.6")
Contrast ratio (typical): 1200:1
Viewing angle, horizontal: 178°
HD type: 4K Ultra HD
Active display area (W x H): 1209.6 x 680.4 mm
Number of simultaneous touchpoints: 40
Touchscreen technology: PureTouch-IR
Glass thickness: 3.2 mm
Surface hardness: 7H
Display brightness: 500 cd/m²
Audio
RMS rated power: 60 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
HDMI version: 2.0
USB connector type: USB Type-A, USB Type-C
DisplayPorts quantity: 1
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
DisplayPort version: 1.2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 3
USB port: Yes
Compatible memory cards: MicroSD (TransFlash)
USB Type-C DisplayPort Alternate Mode: Yes
HDMI input ports quantity: 2
USB Power Delivery (USB PD): Yes
OPS module slot: Yes
USB Power Delivery up to: 100 W
USB ports quantity: 6
RS-232C: Yes
Audio Return Channel (ARC): Yes
HDMI output ports quantity: 1
USB 2.0 Type-B ports quantity: 1
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Quick start guide: Yes
Bluetooth: Yes
Power supply type: Internal
Brightness: 500 cd/m²
Bluetooth version: 5.0
Computer system
Internal memory: 8 GB
Built-in processor: Yes
On-board graphics card model: Mali-G52 MC3
Operating system installed: Android
Computer system: Yes
Internal storage capacity: 128 GB
Operating system version: 14
Processor architecture: ARM Cortex-A53+Cortex-A72
