Design
Product colour: Black
Glass thickness: 3.3 mm
Market positioning: Business
Front bezel colour: Black
Power
Power consumption (off): 0.3 W
AC adapter output voltage: 12 V
Power consumption (typical): 6 W
European Product Registry for Energy Labelling (EPREL) code: 378636
Power consumption (standby): 0.7 W
Energy efficiency scale: A to G
Power supply type: External
Energy consumption (SDR) per 1000 hours: 6 kWh
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): C
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width (with stand): 260.5 mm
Depth (with stand): 39.5 mm
Height (with stand): 183.5 mm
Width (without stand): 260.5 mm
Depth (without stand): 39.5 mm
Height (without stand): 183.5 mm
Weight (with stand): 1.4 kg
Weight (without stand): 2.7 kg
Network
Ethernet LAN: Yes
Performance
NVIDIA G-SYNC: No
AMD FreeSync: No
Palm rejection: Yes
Packaging data
Package weight: 2.7 kg
Package height: 160 mm
Package width: 310 mm
Package depth: 370 mm
Packaging content
Cables included: USB, AC, HDMI, DisplayPort
Quick start guide: Yes
Remote control included: Yes
Display
Display brightness (typical): 500 cd/m²
Response time: 29 ms
Display diagonal: 25.6 cm (10.1")
Display resolution: 1280 x 800 pixels
Native aspect ratio: 16:10
Digital horizontal frequency: 30 - 49.7 kHz
Screen shape: Flat
Viewing angle, vertical: 178°
Display number of colours: 16.7 million colours
Horizontal scan range: 30 - 49.7 kHz
Pixel pitch: 0.1695 x 0.1695 mm
Viewing angle, horizontal: 178°
HD type: HD
Display diagonal (metric): 25.7 cm
Panel type: IPS
Touchscreen: Yes
Number of simultaneous touchpoints: 10
Touchscreen technology: Projected capacitive system
Maximum refresh rate: 75 Hz
Display technology: LED
Viewable size, horizontal: 21.7 cm
Contrast ratio (typical): 800:1
Display brightness: 425 cd/m²
Surface hardness: 7H
Touch technology: Multi-touch
Viewable size, vertical: 13.6 cm
Display brightness (peak): 500 cd/m²
Ergonomics
LED indicators: Yes
Panel mounting interface: 100 x 100 mm
Number of OSD languages: 7
VESA mounting: Yes
Plug and Play: Yes
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Spanish, Japanese, English, German, Italian, Traditional Chinese, French
Wall mountable: Yes
Ports & interfaces
HDCP: Yes
DisplayPorts quantity: 1
HDMI ports quantity: 1
DVI port: No
VGA (D-Sub) ports quantity: 1
Built-in USB hub: Yes
Number of upstream ports: 1
HDMI: Yes
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CB, CE, TÜV-Bauart, EAC, cULus
Packaging content: AC adapter, external control pad
Other features
Ethernet LAN (RJ-45) ports: 1
Depth: 39.5 mm
International Protection (IP) code: IP65
Width: 260.5 mm
Weight: 1.4 kg
AC adapter included: Yes
Compliance certificates: UKCA, REACH, RoHS, CE, EAC, cULus, WEEE
Height: 183.5 mm
Placement supported: Indoor
USB ports quantity: 1
Active display area (W x H): 216.96 x 135.6 mm
Mean time between failures (MTBF): 50000 h
Audio out (mini jack): 1
Brightness: 425 cd/m²
Touch method: stylus, finger, glove (latex)
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Sustainability
Sustainability certificates: ErP
