Design
Glass thickness: 6 mm
Front bezel colour: Black
Product colour: Black
Power
Power supply type: External
Power consumption (typical): 16 W
Energy consumption (SDR) per 1000 hours: 10 kWh
Energy efficiency class (SDR): E
Power consumption (standby): 1.2 W
Energy efficiency scale: A to G
AC adapter output voltage: 12 V
Power consumption (off): 1.2 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight (with stand): 2.9 kg
Height (with stand): 291 mm
Width (without stand): 364 mm
Height (without stand): 41.5 mm
Width (with stand): 364 mm
Depth (without stand): 291 mm
Weight (without stand): 2.9 kg
Depth (with stand): 41.5 mm
Performance
Linux operating systems supported: Yes
Windows operating systems supported: Yes
NVIDIA G-SYNC: No
AMD FreeSync: No
Packaging data
Package weight: 4.6 kg
Package height: 470 mm
Package width: 460 mm
Package depth: 175 mm
Packaging content
Cables included: HDMI, AC, DisplayPort, USB
Quick start guide: Yes
Display
Display brightness: 315 cd/m²
Surface hardness: 7H
Pixel pitch: 0.297 x 0.297 mm
Display resolution: 1024 x 768 pixels
Display number of colours: 16.2 million colours
Native aspect ratio: 4:3
Aspect ratio: 4:3
Display technology: LED
Response time: 8 ms
Viewing angle, vertical: 150°
Horizontal scan range: 31.4 - 60 kHz
Number of simultaneous touchpoints: 10
Panel type: TN
Display diagonal: 38.1 cm (15")
Contrast ratio (typical): 800:1
Viewable size, horizontal: 30.4 cm
Screen shape: Flat
Touch technology: Multi-touch
Viewable size, vertical: 22.8 cm
Touchscreen: Yes
Display diagonal (metric): 38 cm
Touchscreen technology: Projected capacitive system
Display brightness (typical): 350 cd/m²
HD type: XGA
Maximum refresh rate: 75 Hz
Viewing angle, horizontal: 160°
Multimedia
Built-in microphone: No
Built-in camera: No
Ergonomics
On Screen Display (OSD) languages: Japanese, Traditional Chinese, French, Spanish, German, Italian, English
LED indicators: Yes
Panel mounting interface: 100 x 100 mm
Plug and Play: Yes
Wall mountable: Yes
Number of OSD languages: 7
VESA mounting: Yes
On Screen Display (OSD): Yes
Ports & interfaces
DisplayPorts quantity: 1
HDMI: Yes
HDMI ports quantity: 1
USB Touch port: Yes
VGA (D-Sub) ports quantity: 1
HDCP: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CB, CE, TÜV-Bauart, EAC, cULus
Packaging content: AC adapter, Touch Panel Driver Disk (CD-ROM), external control pad
Other features
Placement supported: Horizontal/Vertical
Brightness: 315 cd/m²
Height: 291 mm
Width: 364 mm
Active display area (W x H): 304.1 x 228.1 mm
Display viewable area (HxV): 304.1 x 228.1 mm
Touch method: stylus, finger, glove (latex)
Control panel: menu,scroll up/ brightness, scroll down/ contrast, select, power
International Protection (IP) code: IP65
Depth: 41.5 mm
Weight: 2.9 kg
AC adapter included: Yes
Compliance certificates: CB, EAC, cULus, WEEE, RoHS, CE, REACH
Logistics data
Harmonized System (HS) code: 85285210
Products per pallet: 44 pc(s)
Pallet net width: 86 cm
Pallet net length: 12 cm
Pallet net height: 97 cm
Sustainability
Sustainability certificates: ErP
