Design
Front bezel colour: Black
Glass thickness: 3 mm
Product colour: Black
Power
Energy efficiency class (HDR): Not available
Power consumption (typical): 13 W
Energy efficiency class (SDR): E
Power consumption (standby): 0.6 W
Energy consumption (SDR) per 1000 hours: 11.4 kWh
Power supply type: External
AC adapter output voltage: 12 V
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Weight & dimensions
Weight (without stand): 3.6 kg
Depth (without stand): 47.5 mm
Width (without stand): 369 mm
Height (with stand): 307 mm
Height (without stand): 307 mm
Width (with stand): 369 mm
Depth (with stand): 47.5 mm
Weight (with stand): 3.6 kg
Performance
NVIDIA G-SYNC: No
Palm rejection: Yes
AMD FreeSync: No
Packaging data
Package weight: 4.9 kg
Package width: 455 mm
Package height: 387 mm
Package depth: 145 mm
Packaging content
Quick start guide: Yes
Cables included: HDMI, DisplayPort, AC, USB
Display
Display number of colours: 16.7 million colours
Display resolution: 1280 x 1024 pixels
Number of simultaneous touchpoints: 10
Viewable size, horizontal: 33.8 cm
Touchscreen: Yes
Display brightness (typical): 350 cd/m²
Supported video modes: 1024p
Display brightness: 315 cd/m²
Colour depth: 8 bit
Viewable size, vertical: 27.1 cm
Supported graphics resolutions: 1280 x 1024 (SXGA)
Contrast ratio (typical): 1000:1
Aspect ratio: 5:4
Viewing angle, vertical: 160°
Display technology: LED
Native aspect ratio: 5:4
Display diagonal (metric): 43 cm
Touch technology: Multi-touch
Display diagonal: 43.2 cm (17")
Panel type: TN
Response time: 5 ms
Screen shape: Flat
Horizontal scan range: 31.4 - 80 kHz
Viewable size diagonal: 43 cm
Touchscreen technology: Projected capacitive system
Pixel pitch: 0.264 x 0.264 mm
HD type: SXGA
Viewing angle, horizontal: 170°
Multimedia
Built-in microphone: No
Built-in camera: No
Ergonomics
On Screen Display (OSD) languages: Traditional Chinese, Japanese, Spanish, English, German, Italian, French
Panel mounting interface: 100 x 100 mm
VESA mounting: Yes
Plug and Play: Yes
Number of OSD languages: 7
On Screen Display (OSD): Yes
Ports & interfaces
HDCP: Yes
USB Touch port: Yes
DisplayPorts quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI: Yes
USB Touch ports quantity: 1
USB required: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CE, EAC, RoHS support, ErP, WEEE, cULus, REACH
Packaging content: AC adapter
Other features
Placement supported: Horizontal/Vertical
Active display area (W x H): 338 x 270.5 mm
Supplied AC adapter type: Yes
Width: 369 mm
International Protection (IP) code: IP65
Brightness: 315 cd/m²
Display viewable area (HxV): 338 x 270 mm
Weight: 3.6 kg
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Compliance certificates: EAC, cULus, RoHS, CE, REACH, WEEE
Height: 307 mm
Touch method: Stylus, Finger, Glove
Depth: 47.5 mm
AC adapter included: Yes
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability certificates: ErP
