Technical details
Sustainability certificates: ErP
Compliance certificates: RoHS, CE, WEEE, cTUVus, REACH, UKCA, TÜV mark, CB, EAC
Design
Product colour: Black
Product design: Kiosk design
VESA mounting: Yes
Panel mounting interface: 400 x 400
Screen shape: Flat
Placement supported: Indoor
Bezel width (bottom): 3 cm
Anti-glare screen: Yes
Bezel colour: Black
Bezel width (top): 3 cm
Bezel width (side): 3 cm
Orientation: Horizontal/Vertical
Power
AC input voltage: 100 - 240 V
Power consumption (off): 0.3 W
Power consumption (standby): 0.4 W
Power consumption (typical): 139 W
AC input frequency: 50/60 Hz
Energy efficiency class (SDR): F
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 78 kWh
Energy efficiency scale: A to G
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width (with stand): 1274 mm
Weight: 39.6 kg
Depth (with stand): 65.2 mm
Width: 1274 mm
Height: 744.8 mm
Depth: 65.2 mm
Height (with stand): 744.8 mm
Display weight: 39.6 kg
Display width: 1274 mm
Display depth: 65.2 mm
Display height: 744.8 mm
Weight (with stand): 39.6 kg
Network
Ethernet LAN: Yes
Performance
On Screen Display (OSD): Yes
Purpose: Universal
HDCP: Yes
International Protection (IP) code: IP65
Mean time between failures (MTBF): 50000 h
HDCP version: 2.2
Operating hours (hours/days): 24/7
On Screen Display (OSD) languages: Spanish, Finnish, Danish, Polish, Russian, Czech, Swedish, English, Norwegian, German, Italian, Dutch, French
Number of OSD languages: 13
Packaging data
Package weight: 47.2 kg
Package depth: 185 mm
Package width: 1428 mm
Package height: 894 mm
Package volume: 47200 cm³
Packaging content
Cables included: HDMI, USB, AC
Remote control included: Yes
Batteries included: Yes
Display
HD type: 4K Ultra HD
Display resolution: 3840 x 2160 pixels
Viewing angle, horizontal: 178°
Native aspect ratio: 16:9
Display technology: LED
Contrast ratio (typical): 1200:1
Response time: 8 ms
LED backlight: Yes
Panel type: IPS
Touchscreen: Yes
Pixel pitch: 0.315 x 0.315 mm
Display diagonal: 138.7 cm (54.6")
Display number of colours: 1.07 billion colours
Display diagonal (metric): 139 cm
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Glass thickness: 4 mm
Display brightness: 435 cd/m²
Surface hardness: 7H
Number of simultaneous touchpoints: 40
Multi-touch: Yes
Native refresh rate: 60 Hz
Touchscreen technology: Projected capacitive system
Active display area (W x H): 1209.6 x 680.4 mm
Haze rate: 25%
Audio
RMS rated power: 20 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
HDMI ports quantity: 2
DVI port: No
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-A, USB Type-B
USB port: Yes
HDMI version: 2.0
DisplayPort version: 1.2
RS-232C: Yes
USB 2.0 Type-B ports quantity: 1
USB ports quantity: 2
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Power supply type: Internal
Viewable size, horizontal: 121 cm
Quick start guide: Yes
Display surface: Matt
Viewable size, vertical: 68 cm
Maximum refresh rate: 60 Hz
Brightness: 435 cd/m²
Computer system
Operating system installed: Android 11
Processor manufacturer: ARM
Internal memory: 4 GB
Built-in processor: Yes
On-board graphics card model: ARM Mali-G52
Processor architecture: ARM Cortex-A73
Internal storage capacity: 32 GB
Computer system: Yes
Operating system version: 11
