Technical details
Compliance certificates: RoHS, CE, REACH, cTUVus, WEEE, UKCA, TÜV mark, CB, EAC
Sustainability certificates: ErP
Design
Bezel colour: Black
Screen shape: Flat
Panel mounting interface: 400 x 400
VESA mounting: Yes
Product design: Kiosk design
Product colour: Black
Bezel width (bottom): 3.15 cm
Bezel width (side): 3.15 cm
Anti-glare screen: Yes
Bezel width (top): 3.15 cm
Orientation: Horizontal/Vertical
Placement supported: Indoor
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 183 W
Power consumption (off): 0.3 W
Power consumption (standby): 0.3 W
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 102 kWh
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): F
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Height: 870 mm
Depth (with stand): 66 mm
Height (with stand): 870 mm
Weight: 53.7 kg
Width (with stand): 1495 mm
Width: 1495 mm
Depth: 66 mm
Display weight: 53.7 kg
Display height: 870 mm
Display depth: 66 mm
Weight (with stand): 53.7 kg
Display width: 1495 mm
Network
Ethernet LAN: Yes
Performance
Purpose: Universal
International Protection (IP) code: IP65
HDCP: Yes
Mean time between failures (MTBF): 50000 h
Operating hours (hours/days): 24/7
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Finnish, Spanish, Polish, Russian, Czech, English, Norwegian, Swedish, German, Italian, Dutch, Danish, French
Number of OSD languages: 13
HDCP version: 2.2
Packaging data
Package weight: 65 kg
Package height: 1010 mm
Package width: 1650 mm
Package depth: 194 mm
Package volume: 65000 cm³
Packaging content
Cables included: USB, HDMI, AC
Batteries included: Yes
Remote control included: Yes
Display
LED backlight: Yes
Display diagonal: 163.8 cm (64.5")
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Display number of colours: 1.07 billion colours
Response time: 8 ms
Touchscreen: Yes
Pixel pitch: 0.372 x 0.372 mm
Display resolution: 3840 x 2160 pixels
Native aspect ratio: 16:9
HD type: 4K Ultra HD
Viewing angle, horizontal: 178°
Display technology: LED
Display brightness: 435 cd/m²
Panel type: IPS
Native refresh rate: 60 Hz
Display diagonal (metric): 163.9 cm
Multi-touch: Yes
Active display area (W x H): 1428.5 x 803.5 mm
Glass thickness: 4 mm
Touchscreen technology: Projected capacitive system
Contrast ratio (typical): 1200:1
Surface hardness: 7H
Haze rate: 25%
Number of simultaneous touchpoints: 40
Audio
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20 W
Ports & interfaces
DVI port: No
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 1.2
USB connector type: USB Type-B, USB Type-A
HDMI ports quantity: 2
HDMI version: 2.0
USB ports quantity: 2
USB port: Yes
RS-232C: Yes
USB 2.0 Type-B ports quantity: 1
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Display surface: Matt
Quick start guide: Yes
Viewable size, horizontal: 142.8 cm
Maximum refresh rate: 60 Hz
Brightness: 435 cd/m²
Power supply type: Internal
Viewable size, vertical: 80.3 cm
Computer system
Operating system installed: Android 11
On-board graphics card model: ARM Mali-G52
Processor manufacturer: ARM
Internal memory: 4 GB
Internal storage capacity: 32 GB
Computer system: Yes
Processor architecture: ARM Cortex-A73
Operating system version: 11
Built-in processor: Yes
