Technical details
Sustainability certificates: ErP
Audio in (mini jack): Yes
Compliance certificates: REACH, UKCA, EAC, WEEE, RoHS, CE
User controls: Power, home, brightness +, brightness -, volume +, volume -
Internal memory: 32000 MB
Features
Suitable for indoor use: Yes
Design
Orientation: Horizontal/Vertical
Fingerprint resistant: Yes
Bezel colour: Black
VESA mounting: Yes
Product design: Kiosk design
Product colour: Black
Power
Input voltage: 12 V
Power consumption (typical): 18 W
Power consumption (off): 0.3 W
Power consumption (standby): 0.5 W
Weight & dimensions
Display depth: 30.5 mm
Display height: 172 mm
Display weight: 800 g
Display width: 255 mm
Weight: 800 g
Height: 172 mm
Depth: 30.5 mm
Width: 255 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, 802.11g, 802.11b, Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Operating hours (hours/days): 24/7
Purpose: Universal
Number of microphones: 1
Packaging data
Package height: 223 mm
Package width: 398 mm
Package weight: 1.36 kg
Package depth: 68 mm
Packaging content
Power adapter included: Yes
Cables included: AC
Display
Colour depth: 8 bit
Active display area (W x H): 216.6 x 135.4 mm
Glass thickness: 1.25 mm
Touchscreen technology: Projected capacitive system
Surface hardness: 6H
Multi-touch: Yes
Number of simultaneous touchpoints: 10
Native aspect ratio: 16:10
Response time: 25 ms
Panel type: IPS
Display diagonal (metric): 25.5 cm
Display number of colours: 16.7 million colours
Viewing angle, vertical: 160°
Display brightness: 385 cd/m²
Touchscreen: Yes
Contrast ratio (typical): 1000:1
Display resolution: 1280 x 800 pixels
Pixel pitch: 0.1692 x 0.1692 mm
Viewing angle, horizontal: 160°
HD type: WXGA
Display diagonal: 25.6 cm (10.1")
Audio
RMS rated power: 3 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
HDMI input ports quantity: 1
USB ports quantity: 4
PC Audio in: Yes
Mini HDMI ports quantity: 1
DC-in jack: Yes
USB port: Yes
USB connector type: USB Type-A, Micro-USB
Ethernet LAN (RJ-45) ports: 1
Compatible memory cards: SD
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Card reader integrated: Yes
Other features
Brightness: 385 cd/m²
Micro-USB ports quantity: 1
Cable management: Yes
RJ-45 ports quantity: 1
Megapixel (approx.): 5 MP
Power supply type: External
Quick start guide: Yes
Built-in microphone: Yes
Viewable size, vertical: 13.5 cm
USB 2.0 ports quantity: 2
Viewable size, horizontal: 21.7 cm
Audio input: Y
Bluetooth version: 5.2
AC adapter included: Yes
Bluetooth: Yes
Built-in camera: Yes
Logistics data
Pallet gross height: 120 cm
Pallet gross width: 2.15 m
Pallet gross length: 100 cm
Products per pallet: 256 pc(s)
Computer system
Operating system version: 13
Internal storage capacity: 32 GB
Google applications: Google Chrome, Gmail, Google Calendar
Internal memory: 4 GB
Processor manufacturer: Rockchip
On-board graphics card model: Mali-G52 MC1
Processor cores: 4
Built-in processor: Yes
Processor model: RK3568
Operating system installed: Android
Processor family: ARM Rockchip
Processor frequency: 2 GHz
