Technical details
Compliance certificates: REACH, RoHS, CE, EAC, UKCA, WEEE
User controls: Power switch, volume/ button +, volume/ button -
Sustainability certificates: ErP
Design
Bezel colour: Black
Product colour: Black
Product design: Kiosk design
VESA mounting: Yes
Panel mounting interface: 100 x 100 mm
Placement supported: Indoor
Orientation: Horizontal/Vertical
Power
Power consumption (off): 0.3 W
Power consumption (typical): 36.34 W
Power consumption (standby): 0.5 W
Weight & dimensions
Depth (with stand): 35 mm
Width (with stand): 735 mm
Height (with stand): 436 mm
Weight: 7.7 kg
Height: 436 mm
Weight (with stand): 7.7 kg
Depth: 35 mm
Display weight: 7.7 kg
Display width: 735 mm
Width: 735 mm
Display height: 436 mm
Display depth: 35 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Ethernet LAN data rates: 10, 1000, 100 Mbit/s
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
HDCP: Yes
Operating hours (hours/days): 24/7
Purpose: Universal
Mean time between failures (MTBF): 50000 h
Packaging data
Package weight: 12.4 kg
Package depth: 126 mm
Package width: 833 mm
Package height: 508 mm
Packaging content
Mounting kit: Yes
Cables included: AC
Power adapter included: Yes
Display
Display diagonal: 80 cm (31.5")
HD type: Full HD
Viewing angle, horizontal: 178°
Pixel pitch: 0.3637 x 0.3637 mm
Display resolution: 1920 x 1080 pixels
Response time: 8 ms
Display number of colours: 16.7 million colours
Native aspect ratio: 16:9
Viewing angle, vertical: 178°
Touchscreen technology: Projected capacitive system
Display diagonal (metric): 80.1 cm
Contrast ratio (typical): 4000:1
Touchscreen: Yes
Panel type: VA
Colour depth: 8 bit
Multi-touch: Yes
Display brightness: 430 cd/m²
Active display area (W x H): 698.4 x 392.8 mm
Number of simultaneous touchpoints: 10
Surface hardness: 3H
Display technology: LED
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 10 W
Ports & interfaces
DC-in jack: Yes
HDMI version: 1.4
Ethernet LAN (RJ-45) ports: 1
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB connector type: USB Type-C, USB Type-A
HDMI ports quantity: 1
USB version: 3.2 Gen 1 (3.1 Gen 1)
USB ports quantity: 3
HDMI input ports quantity: 1
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Microphone in: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
AC adapter included: Yes
Bluetooth: Yes
Quick start guide: Yes
Cable management: Yes
Viewable size, vertical: 39.3 cm
Audio output: Mini Jack
Bluetooth version: 5.3
Power supply type: External
Brightness: 430 cd/m²
Viewable size, horizontal: 69.8 cm
Computer system
Processor cores: 8
On-board graphics card model: Mali-G52 MC3
Processor model: Rockchip RK3576
Processor family: ARM Rockchip
Internal memory: 4 GB
Processor manufacturer: ARM
Google applications: Gmail, Google Chrome, Google Calendar
Operating system installed: Android
Internal storage capacity: 32 GB
Processor architecture: ARM Cortex-A53+Cortex-A72
Operating system version: 14
Built-in processor: Yes
