Design
Protection features: Waterproof
Housing material: Plastic
Mounting type: Ceiling/wall
International Protection (IP) code: IP66
Form factor: Turret
Product colour: Black, White
Power
Power consumption (max): 12 W
DC output current: 1 A
Power source type: DC
DC output voltage: 12
Security
Video motion detection: Yes
Configurable region: Yes
Intelligent Video Surveillance (IVS) system features: Human detection, Vehicle detection
Built-in siren: Yes
Siren noise level: 110 dB
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 50 °C
Management features
Reset button: Yes
Weight & dimensions
Width: 129 mm
Height: 110 mm
Weight: 438 g
Depth: 110 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Bluetooth: No
Performance
Type: IP security camera
Day/night mode: Yes
Built-in light: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired & Wireless
Packaging content
Mounting kit: Yes
Quick start guide: Yes
Screws included: Yes
Number of cameras: 1
AC adapter included: Yes
Audio
Built-in speaker(s): Yes
Built-in microphone: Yes
Storage
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Maximum memory card size: 512 GB
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Viewing angle, diagonal (2.8mm lens): 113.7°
Viewing angle, horizontal (2.8mm lens): 95.3°
Viewing angle, vertical (2.8mm lens): 52.1°
Pan range: 0 - 355°
Lens viewing angle, horizontal: 24.4°
Tilt angle range: 0 - 90°
Lens viewing angle, diagonal: 28.1°
Lens viewing angle, vertical: 14°
Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 3 mm (1 / 3")
Progressive scan: Yes
Sensor type: CMOS
Video
Frame rate: 15 fps
Video compression formats: H.265, H.264
Total megapixels: 5 MP
Night vision
Night vision distance: 56 m
LED type: White
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Zoom capability: Yes
Digital zoom: 12x
Fixed focal length: 12 mm
Number of lenses: 1
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Sustainability
Compliance certificates: CE
