Design
Product colour: White, Black
Form factor: Dome
Mounting type: Wall
Housing material: Plastic
Power
Power consumption (max): 12 W
Power source type: DC, PoE
DC output voltage: 12
DC output current: 1 A
Security
Siren noise level: 125 dB
Built-in siren: Yes
Motion sensor: Yes
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Human detection
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
Weight & dimensions
Height: 238.2 mm
Width: 147.7 mm
Depth: 182.3 mm
Weight: 723.6 g
Network
Wi-Fi standards: 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g
Wi-Fi: Yes
Performance
Connectivity technology: Wireless
Type: IP security camera
Placement supported: Indoor & outdoor
Packaging content
Number of cameras: 1
Audio
Audio system: 2-way
Built-in microphone: Yes
Built-in speaker(s): Yes
Storage
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB
Built-in HDD: No
Camera
Tilt angle range: 0 - 90°
Lens viewing angle, horizontal: 89°
Lens viewing angle, vertical: 47°
Lens viewing angle, diagonal: 107°
Pan range: 0 - 340°
Image sensor
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Sensor type: CMOS
Video
Maximum resolution: 3200 x 1800 pixels
Total megapixels: 6 MP
Frame rate: 20 fps
Video compression formats: H.264, H.265
Night vision
Night vision distance: 30 m
Night vision: Yes
Lens system
Maximum aperture number: 1
Fixed focal length: 3.6 mm
Fixed focus: Yes
Digital zoom: 8x
Zoom capability: Yes
