Design
Mounting type: Wall
Product colour: White, Black
LED indicators: Yes
International Protection (IP) code: IP66
Power
DC output current: 1 A
DC output voltage: 12V
Power source type: DC
Security
Video motion detection: Yes
Operational conditions
Operating temperature (T-T): -30 - 50 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
Weight & dimensions
Depth: 159 mm
Height: 196 mm
Width: 126 mm
Weight: 446 g
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 100
Wi-Fi: Yes
System requirements
Mobile operating systems supported: iOS, Android
Performance
Placement supported: Outdoor
Infrared (IR) cut-off filter: Yes
Remote viewing: Yes
Auto-tracking: Yes
Day/night mode: Yes
Connectivity technology: Wired & Wireless
Type: IP security camera
Packaging content
Number of cameras: 1
Audio
Built-in speaker(s): No
Built-in microphone: Yes
Storage
Maximum memory card size: 512 GB
Compatible memory cards: MicroSD (TransFlash), MicroSDXC, MicroSDHC
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera tilt control: Yes
Camera pan control: Yes
Pan range: 0 - 355°
Viewing angle, diagonal: 89°
Tilt angle range: 0 - 90°
Viewing angle, vertical: 40°
Viewing angle, horizontal: 73°
Image sensor
Optical sensor size: 25.4 / 3 mm (1 / 3")
Sensor type: CMOS
Number of sensors: 1
Video
Total megapixels: 5 MP
Video compression formats: H.265, H.264
Maximum resolution: 2880 x 1620 pixels
Night vision
LED type: IR
Night vision: Yes
Number of infrared LEDs: 4
Night vision distance: 30 m
Lens system
Digital zoom: 8x
Fixed focal length: 3.6 mm
Number of lenses: 1
Zoom capability: Yes
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
