Design Number of fans: 1 fan(s) Cooling type: Active Fan diameter: 12 cm Product colour: Black
Power Maximum input current (@220V): 10 A Max output current (-12V): 0.3 A Max output current (+5Vsb): 2 A Power protection features: Over voltage, Under voltage, Over current AC input frequency: 50/60 Hz Total power: 750 W Max output current (+5V): 20 A AC input voltage: 200 - 240 V Input current: 10 A Combined power (+3.3V): 103 W Combined power (-12V): 3.6 W Max output current (+12V): 58 A Combined power (+12V): 696 W Combined power (+5V): 103 W Max output current (+3.3V): 16 A Combined power (+5Vsb): 10 W
Weight & dimensions Width: 140 mm Depth: 150 mm Height: 86 mm
Performance Power supply unit (PSU) form factor: ATX Purpose: PC 80 PLUS certification: 80 PLUS Gold ATX version: 2.4
Certificates Compliance certificates: CE, CCC
Ports & interfaces Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular PCI Express power connectors (6+2 pin): 2
