Features
Output power capacity: 1 kVA
Input frequency: 47 - 63 Hz
Audible alarm modes: Alarm when on battery, Fault, Overload alarm, Low battery alarm
Crest factor: 3:1
Power factor: 0.8
Audible alarm(s): Yes
Input power factor: 0.99
Maximum current: 10 A
Output operation voltage (min): 100 V
Efficiency: 88%
Output voltage regulation: -1 - 1%
Output voltage Total Harmonic Distortion (THD): 6%
Number of output phases: 1
ECO mode: Yes
Output frequency: 47/63 Hz
Waveform: Pure sine
Input operation voltage (max): 240 V
UPS topology: Double-conversion (Online)
Response time: 4 ms
Noise level: 50 dB
Input operation voltage (min): 100 V
Output operation voltage (max): 240 V
Number of input phases: 1
Design
Display type: LED
Form factor: Tower
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Weight & dimensions
Depth: 220 mm
Width: 145 mm
Weight: 8.6 kg
Height: 282 mm
Packaging content
Manual: Yes
Cables included: Output power cable, RS-232, Input power cable
Certification: CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Serial interface type: RS-232
AC outlet types: C13 coupler
Serial interface: Yes
AC outlets quantity: 3 AC outlet(s)
Serial ports quantity: 1
Battery
Charging current: 1 A
Battery capacity: 9 Ah
Typical backup time at full load: 30 min
Battery technology: Sealed Lead Acid (VRLA)
Cold start: Yes
Battery voltage: 12 V
Typical backup time at half load: 9 min
Battery recharge time: 4 h
Safety warning
Warnings: Store away from sources of heat and open flame., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
