Intel Core i5-12400F processor 18 MB Smart Cache Box

Technical details
Launch date: Q1'22
Status: Launched

Processor
Processor manufacturer: Intel
Processor threads: 12
Processor model: i5-12400F
Maximum number of DMI lanes: 8
Processor operating modes: 64-bit
Processor codename: Alder Lake
Processor cores: 6
Maximum turbo power: 117 W
Performance cores: 6
Box: Yes
Performance-core base frequency: 2.5 GHz
Processor family: Intel® Core™ i5
Processor generation: 12th gen Intel® Core™ i5
Performance-core boost frequency: 4.4 GHz
Processor base power: 65 W
Processor cache: 18 MB
Processor cache type: Smart Cache
Processor socket: LGA 1700

Graphics
Discrete graphics card: No
Discrete graphics card model: Not available
On-board graphics card: No
On-board graphics card model: Not available

Features
Scalability: 1S
CPU configuration (max): 1
Supported instruction sets: SSE4.2, AVX 2.0, SSE4.1
Export Control Classification Number (ECCN): 5A992CN3
Commodity Classification Automated Tracking System (CCATS): G167599
Embedded options available: No
Direct Media Interface (DMI) Revision: 4.0
Harmonized System (HS) code: 8542310001
Thermal Monitoring Technologies: Yes
PCI Express configurations: 1x16+1x4, 2x8+1x4
PCI Express slots version: 4.0, 5.0
Idle States: Yes
Execute Disable Bit: Yes
Market segment: Desktop
Maximum number of PCI Express lanes: 20

Memory
Memory bandwidth (max): 76.8 GB/s
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor: 128 GB
Memory channels: Dual-channel

Operational conditions
Tjunction: 100 °C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Intel® Turbo Boost Technology: 2.0
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Volume Management Device (VMD): Yes
Intel® Optane™ Memory Ready: Yes
Intel® Boot Guard: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel 64: Yes
Intel® Thread Director: No
Intel® Secure Key: Yes
Intel Virtualization Technology (VT-x): Yes
Intel® OS Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel Turbo Boost Max Technology 3.0: No
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Speed Shift Technology: Yes

Safety warning
Warnings: Do not dispose of the processors in the normal rubbish bin - they require special disposal due to their potential environmental impact.
