Intel Core i5-12600KF processor 20 MB Smart Cache Box

Technical details
Launch date: Q4'21
Status: Launched
Target market: Gaming

Processor
Performance cores: 6
Processor base power: 125 W
Performance-core boost frequency: 4.9 GHz
Processor generation: 12th gen Intel® Core™ i5
Efficient-core base frequency: 2.8 GHz
Efficient-core boost frequency: 3.6 GHz
Performance-core base frequency: 3.7 GHz
Efficient cores: 4
Maximum number of DMI lanes: 8
Maximum turbo power: 150 W
Processor threads: 16
Processor manufacturer: Intel
Component for: PC
Processor ARK ID: 134590
Processor socket: LGA 1700
Processor cores: 10
Cooler included: No
Processor family: Intel® Core™ i5
Memory bandwidth supported by processor (max): 76.8 GB/s
Processor cache: 20 MB
Box: Yes
Processor boost frequency: 4.9 GHz
Processor codename: Alder Lake
Bus type: DMI4
Processor cache type: Smart Cache
Processor operating modes: 64-bit
Processor model: i5-12600KF

Graphics
Discrete graphics card: No
On-board graphics card model: Not available
Discrete graphics card model: Not available
On-board graphics card: No

Features
Use conditions: PC/Client/Tablet
Commodity Classification Automated Tracking System (CCATS): G167599
PCI Express configurations: 1x16+1x4, 2x8+1x4
CPU configuration (max): 1
Idle States: Yes
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Embedded options available: No
Scalability: 1S
Thermal Monitoring Technologies: Yes
Market segment: Desktop
Maximum number of PCI Express lanes: 20
Execute Disable Bit: Yes
Thermal solution specification: PCG 2020A
PCI Express slots version: 4.0, 5.0
Export Control Classification Number (ECCN): 5A992CN3

Memory
Non-ECC: Yes
Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max): 76.8 GB/s
Memory channels: Dual-channel

Operational conditions
Tjunction: 100 °C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Intel® Thread Director: Yes
Intel® Standard Manageability (ISM): Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel® Secure Key: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Turbo Boost Technology: 2.0
Intel VT-x with Extended Page Tables (EPT): Yes
Intel Turbo Boost Max Technology 3.0: No
Intel® Boot Guard: Yes
Intel® Speed Shift Technology: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Mode-based Execute Control (MBE): Yes
Intel® Optane™ Memory Ready: Yes
Intel 64: Yes
Intel® Volume Management Device (VMD): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® OS Guard: Yes

Other features
Maximum internal memory: 128 GB

Logistics data
Harmonized System (HS) code: 85423119
