Intel Core i5-14600KF processor 24 MB Smart Cache Box

Technical details
Status: Launched
Launch date: Q4'23

Processor
Processor generation: Intel® Core™ i5 (14th gen)
Maximum turbo power: 181 W
Performance-core boost frequency: 5.3 GHz
Maximum number of DMI lanes: 8
Box: Yes
Cooler included: No
Processor base power: 125 W
Efficient cores: 8
Performance-core base frequency: 3.5 GHz
Performance cores: 6
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor operating modes: 64-bit
Processor threads: 20
Stepping: B0
Processor cache: 24 MB
Processor cores: 14
Processor socket: LGA 1700
Processor model: i5-14600KF
Processor ARK ID: 236778
Processor family: Intel® Core™ i5
Processor manufacturer: Intel
Processor cache type: Smart Cache

Graphics
Discrete graphics card: No
Discrete graphics card model: Not available
On-board graphics card model: Not available
On-board graphics card: No

Features
Supported instruction sets: AVX 2.0, SSE4.2, SSE4.1
Use conditions: PC/Client/Tablet
Scalability: 1S
Thermal solution specification: PCG 2020A
Market segment: Desktop
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Execute Disable Bit: Yes
Thermal Monitoring Technologies: Yes
PCI Express configurations: 1x16+1x4, 2x8+1x4
Embedded options available: No
CPU configuration (max): 1
Idle States: Yes
PCI Express slots version: 5.0, 4.0
Maximum number of PCI Express lanes: 20

Memory
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max): 89.6 GB/s
Memory channels: Dual-channel
Non-ECC: Yes

Operational conditions
Tjunction: 100 °C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Mode-based Execute Control (MBE): Yes
Intel® Boot Guard: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Standard Manageability (ISM): Yes
Intel® Volume Management Device (VMD): Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Speed Shift Technology: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Secure Key: Yes
Intel® Turbo Boost Technology: 2.0
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® OS Guard: Yes
Intel 64: Yes

Other features
L2 cache: 20480 KB
Maximum internal memory: 192 GB

Logistics data
Harmonized System (HS) code: 8542310001

Safety warning
Warnings: Ensure that the CPU is properly mounted in the CPU socket to avoid damage., Do not dispose of the processors in the normal rubbish bin - they require special disposal due to their potential environmental impact.
