Intel Core i9-12900K processor 30 MB Smart Cache Box

Technical details
OpenCL version: 2.1
Status: Launched
Launch date: Q4'21
Target market: Gaming, Content Creation

Processor
Box: Yes
Processor cores: 16
Processor model: i9-12900K
Processor family: Intel® Core™ i9
Processor cache: 30 MB
Processor threads: 24
Processor manufacturer: Intel
Processor codename: Alder Lake
Processor operating modes: 64-bit
Processor cache type: Smart Cache
Memory bandwidth supported by processor (max): 76.8 GB/s
Bus type: DMI4
Component for: PC
Processor socket: LGA 1700
Performance-core base frequency: 3.2 GHz
Efficient cores: 8
Maximum turbo power: 241 W
Processor generation: 12th gen Intel® Core™ i9
Processor base power: 125 W
Performance-core boost frequency: 5.1 GHz
Maximum number of DMI lanes: 8
Performance cores: 8

Graphics
On-board graphics card DirectX version: 12.0
Discrete graphics card: No
On-board graphics card dynamic frequency (max): 1550 MHz
Number of displays supported (on-board graphics): 4
Discrete graphics card model: Not available
Number of execution units: 32
On-board graphics card: Yes
On-board graphics card base frequency: 300 MHz
On-board graphics card model: Intel UHD Graphics 770
On-board graphics card ID: 0x4680
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card OpenGL version: 4.5

Features
Thermal Monitoring Technologies: Yes
PCI Express slots version: 5.0, 4.0
Execute Disable Bit: Yes
Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
CPU configuration (max): 1
PCI Express configurations: 1x16+1x4, 2x8+1x4
Idle States: Yes
Thermal solution specification: PCG 2020A
Embedded options available: No
Scalability: 1S
Maximum number of PCI Express lanes: 20
Market segment: Desktop
Use conditions: PC/Client/Tablet
Commodity Classification Automated Tracking System (CCATS): G167599
Export Control Classification Number (ECCN): 5A992CN3
Harmonized System (HS) code: 8542310001

Memory
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory channels: Dual-channel
Maximum internal memory supported by processor: 128 GB
Memory bandwidth (max): 76.8 GB/s

Operational conditions
Tjunction: 100 °C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Optane™ Memory Ready: Yes
Intel 64: Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel® Quick Sync Video Technology: Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Turbo Boost Technology: 2.0
Intel VT-x with Extended Page Tables (EPT): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel® Volume Management Device (VMD): Yes
Intel® Speed Shift Technology: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel Turbo Boost Max Technology 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Mode-based Execute Control (MBE): Yes
Intel® Boot Guard: Yes
Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz

Other features
Maximum internal memory: 128 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1

Safety warning
Warnings: Do not install on a switched-on device., Protect against overheating., Avoid contact with liquid.
