Intel Core i9-14900K processor 36 MB Smart Cache Box

Technical details
OpenCL version: 3.0
Launch date: Q4'23
Status: Launched

Processor
Processor cache: 36 MB
Processor manufacturer: Intel
Processor family: Intel® Core™ i9
Processor ARK ID: 236773
Stepping: B0
Processor cache type: Smart Cache
Processor operating modes: 64-bit
Processor socket: LGA 1700
Processor codename: Raptor Lake
Processor threads: 32
Processor model: i9-14900K
Processor cores: 24
Box: Yes
Memory bandwidth supported by processor (max): 89.6 GB/s
Efficient cores: 16
Performance cores: 8
Cooler included: No
Maximum turbo power: 253 W
Processor base power: 125 W
Performance-core boost frequency: 5.6 GHz
Maximum number of DMI lanes: 8
Performance-core base frequency: 3.2 GHz
Processor generation: Intel® Core™ i9 (14th gen)

Graphics
Discrete graphics card model: Not available
On-board graphics card DirectX version: 12.0
On-board graphics card: Yes
Number of execution units: 32
Discrete graphics card: No
On-board graphics card model: Intel UHD Graphics 770
On-board graphics card base frequency: 300 MHz
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card outputs supported: HDMI 2.1, DisplayPort 1.4a, Embedded DisplayPort (eDP) 1.4b
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics card ID: 0xA780
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
On-board graphics card OpenGL version: 4.5
Number of displays supported (on-board graphics): 4
On-board graphics card dynamic frequency (max): 1650 MHz
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
Multi-Format Codec Engines: 2

Features
Execute Disable Bit: Yes
Thermal Monitoring Technologies: Yes
CPU configuration (max): 1
PCI Express configurations: 1x16+1x4, 2x8+1x4
Idle States: Yes
PCI Express slots version: 5.0, 4.0
Maximum number of PCI Express lanes: 20
Embedded options available: No
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Export Control Classification Number (ECCN): 5A992C
Supported instruction sets: SSE4.2, SSE4.1, AVX 2.0
Scalability: 1S
Market segment: Desktop
Thermal solution specification: PCG 2020A
Direct Media Interface (DMI) Revision: 4.0
Use conditions: PC/Client/Tablet, Workstation

Memory
ECC: Yes
Memory channels: Dual-channel
Memory bandwidth (max): 89.6 GB/s
Non-ECC: Yes
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM

Operational conditions
Tjunction: 100 °C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Enhanced Intel SpeedStep Technology: Yes
Intel® Quick Sync Video Technology: Yes
Intel® Secure Key: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® OS Guard: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel 64: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Turbo Boost Technology: 2.0
Mode-based Execute Control (MBE): Yes
Intel® Thread Director: Yes
Intel® Turbo Boost Max Technology 3.0 frequency: 5.8 GHz
Intel® Control-flow Enforcement Technology (CET): Yes
Intel Turbo Boost Max Technology 3.0: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Thermal Velocity Boost Frequency: 6 GHz
Intel® Thermal Velocity Boost: Yes
Intel® Volume Management Device (VMD): Yes
Intel® Speed Shift Technology: Yes
Intel® Standard Manageability (ISM): Yes
Intel® Boot Guard: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Adaptive Boost Technology: Yes

Other features
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
L2 cache: 32768 KB

Logistics data
Harmonized System (HS) code: 8542310001

Safety warning
Warnings: Protect against overheating., Avoid contact with liquid., Do not install on a switched-on device.
