Intel Xeon Gold 6414U processor 2 GHz 60 MB Tray

Technical details
Package carrier: E1A
Status: Launched
Supported memory types: DDR4-SDRAM
Memory speed (max): 4800 MHz
Launch date: Q1'23

Processor
Low priority cores: 20
Processor generation: Intel Xeon Scalable 4th Gen
High priority cores: 12
Low priority core frequency: 1.6 GHz
High priority core frequency: 2.1 GHz
Processor base frequency: 2 GHz
Stepping: E5
Processor threads: 64
Processor model: 6414U
Processor operating modes: 64-bit
Processor cores: 32
Processor family: Intel® Xeon® Gold
Processor codename: Sapphire Rapids
Processor cache: 60 MB
Processor boost frequency: 3.4 GHz
System bus rate: 0 GT/s
Processor ARK ID: 231731
Processor socket: LGA 4677 (Socket E)
Thermal Design Power (TDP): 250 W
Processor manufacturer: Intel

Graphics
Discrete graphics card model: Not available
On-board graphics card model: Not available
On-board graphics card: No
Discrete graphics card: No

Features
Use conditions: Server/Enterprise
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): G180729
Maximum number of PCI Express lanes: 80
PCI Express slots version: 5.0
Supported instruction sets: SSE4.2, AVX 2.0, AVX, AMX, AVX-512
Market segment: Server
Scalability: 1S
Execute Disable Bit: Yes

Memory
Memory channels: Octa-channel
Maximum internal memory supported by processor: 6 TB
Memory types supported by processor: DDR4-SDRAM
ECC: Yes

Operational conditions
DTS Max: 93 °C
Tcase: 76 °C

Weight & dimensions
Processor package size: 77.5 x 56.5 mm

Processor special features
Intel® On Demand Feature Activation: Yes
Intel® Optane™ DC Persistent Memory Supported: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Maximum Enclave Size Support for Intel® SGX: 128 GB
Intel® Transactional Synchronization Extensions: Yes
Intel® Crypto Acceleration: Yes
Intel® Platform Firmware Resilience Support: Yes
Intel® Total Memory Encryption: Yes
Intel® Advanced Matrix Extensions (AMX): Yes
Intel® QuickAssist Software Acceleration: Yes
Intel® Data Streaming Accelerator (DSA): 1 default devices
Intel® Turbo Boost Technology: 2.0
Intel Trusted Execution Technology: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Speed Shift Technology: Yes
Intel Virtualization Technology (VT-x): Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Mode-based Execute Control (MBE): Yes
Intel® Resource Director Technology (Intel® RDT): Yes
AVX-512 Fused Multiply-Add (FMA) units: 2
Intel® Run Sure Technology: Yes
Intel 64: Yes
Intel® Boot Guard: Yes
Intel® OS Guard: Yes

Other features
Maximum internal memory: 4 TB

Logistics data
Harmonized System (HS) code: 8542310001
