Intel Xeon Gold 6430 processor 2.1 GHz 60 MB Box

Technical details
Supported memory types: DDR5-SDRAM
Status: Launched
Launch date: Q1'23
Memory speed (max): 4400 MHz
Number of UPI links: 3
Package carrier: E1A

Processor
Processor family: Intel® Xeon® Gold
Processor cache: 60 MB
Processor model: 6430
System bus rate: 16 GT/s
Processor threads: 64
Processor cores: 32
Stepping: E5
Processor boost frequency: 3.4 GHz
Processor operating modes: 64-bit
Processor codename: Sapphire Rapids
Processor ARK ID: 231737
Thermal Design Power (TDP): 270 W
Processor manufacturer: Intel
Processor socket: LGA 4677 (Socket E)
High priority cores: 12
Processor base frequency: 2.1 GHz
High priority core frequency: 2.2 GHz
Low priority core frequency: 1.8 GHz
Low priority cores: 20
Processor generation: Intel Xeon Scalable 4th Gen

Graphics
Discrete graphics card model: Not available
On-board graphics card model: Not available
Discrete graphics card: No
On-board graphics card: No

Features
Maximum number of PCI Express lanes: 80
Embedded options available: Yes
PCI Express slots version: 5.0
Supported instruction sets: AVX 2.0, AMX, AVX-512, AVX, SSE4.2
Scalability: 2S
Market segment: Server
Execute Disable Bit: Yes
Use conditions: Server/Enterprise
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): G180729

Memory
Memory types supported by processor: DDR5-SDRAM
ECC: Yes
Memory channels: Octa-channel
Maximum internal memory supported by processor: 6 TB

Operational conditions
Tcase: 72 °C
DTS Max: 90 °C

Weight & dimensions
Processor package size: 77.5 x 56.5 mm

Processor special features
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel Trusted Execution Technology: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel 64: Yes
Intel® Run Sure Technology: Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
AVX-512 Fused Multiply-Add (FMA) units: 2
Intel® Speed Shift Technology: Yes
Intel® OS Guard: Yes
Intel® Optane™ DC Persistent Memory Supported: Yes
Intel® Resource Director Technology (Intel® RDT): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Mode-based Execute Control (MBE): Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel® QuickAssist Software Acceleration: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Advanced Matrix Extensions (AMX): Yes
Intel® Total Memory Encryption: Yes
Intel® Crypto Acceleration: Yes
Intel® Transactional Synchronization Extensions: Yes
Intel® Data Streaming Accelerator (DSA): 1 default devices
Maximum Enclave Size Support for Intel® SGX: 128 GB
Intel® Platform Firmware Resilience Support: Yes
Intel® On Demand Feature Activation: Yes

Other features
Maximum internal memory: 4 TB

Logistics data
Harmonized System (HS) code: 8542310001

Safety warning
Warnings: The product should be used in accordance with the manufacturer's instructions to avoid damage., Avoid direct contact with water and high humidity., Do not disassemble the processor or attempt to repair it yourself.
