Intel Xeon Gold 6430 processor 2.1 GHz 60 MB Tray

Technical details
Memory speed (max): 4400 MHz
Supported memory types: DDR5-SDRAM
Status: Launched
Launch date: Q1'23
Number of UPI links: 3
Package carrier: E1A

Processor
Processor model: 6430
System bus rate: 16 GT/s
Processor cores: 32
Processor manufacturer: Intel
Processor cache: 60 MB
Stepping: E5
Processor socket: LGA 4677 (Socket E)
Processor ARK ID: 231737
Processor boost frequency: 3.4 GHz
Processor threads: 64
Thermal Design Power (TDP): 270 W
Processor operating modes: 64-bit
Processor codename: Sapphire Rapids
High priority core frequency: 2.2 GHz
Processor generation: Intel Xeon Scalable 4th Gen
Processor base frequency: 2.1 GHz
Low priority core frequency: 1.8 GHz
High priority cores: 12
Low priority cores: 20

Graphics
Discrete graphics card: No
On-board graphics card model: Not available
On-board graphics card: No
Discrete graphics card model: Not available

Features
Market segment: Server
PCI Express slots version: 5.0
Scalability: 2S
Maximum number of PCI Express lanes: 80
Supported instruction sets: SSE4.2, AMX, AVX-512, AVX 2.0, AVX
Execute Disable Bit: Yes
Embedded options available: Yes
Commodity Classification Automated Tracking System (CCATS): G180729
Use conditions: Server/Enterprise
Export Control Classification Number (ECCN): 5A992C

Memory
ECC: Yes
Maximum internal memory supported by processor: 6 TB
Memory types supported by processor: DDR5-SDRAM
Memory channels: Octa-channel

Operational conditions
Tcase: 72 °C
DTS Max: 90 °C

Weight & dimensions
Processor package size: 77.5 x 56.5 mm

Processor special features
Intel® Boot Guard: Yes
Intel® Speed Shift Technology: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel Trusted Execution Technology: Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): Yes
Intel 64: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Mode-based Execute Control (MBE): Yes
Intel® Optane™ DC Persistent Memory Supported: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel® OS Guard: Yes
Intel® Turbo Boost Technology: 2.0
Intel® Run Sure Technology: Yes
AVX-512 Fused Multiply-Add (FMA) units: 2
Intel® Resource Director Technology (Intel® RDT): Yes
Intel® QuickAssist Software Acceleration: Yes
Intel® Crypto Acceleration: Yes
Intel® Total Memory Encryption: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Platform Firmware Resilience Support: Yes
Maximum Enclave Size Support for Intel® SGX: 128 GB
Intel® Data Streaming Accelerator (DSA): 1 default devices
Intel® Transactional Synchronization Extensions: Yes
Intel® On Demand Feature Activation: Yes
Intel® Advanced Matrix Extensions (AMX): Yes

Other features
Maximum internal memory: 4 TB

Logistics data
Harmonized System (HS) code: 8542310001

Safety warning
Warnings: Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity., The product should be used in accordance with the manufacturer's instructions to avoid damage.
