Features Overheat protection: Yes Frequency range: 864 MHz (Long Range), 868.4 MHz (Mesh) LED indicators: Yes Maximum indoor range: 80 m Product colour: Black DIN rail mounting: Yes Connectivity: Z-Wave Overcurrent protection: Yes Product type: Smart relay Housing material: Plastic Remotely operated: Yes Cable section: 0.5 - 2.5 mm² Security: AES-128
Power Power consumption (typical): 0.3 W Maximum switching voltage (AC): 240 V AC input voltage: 110 - 240 V Maximum switching current (AC): 16 A AC input frequency: 50/60 Hz
Operational conditions Operating relative humidity (H-H): 30 - 70% Operating temperature (T-T): -20 - 40 °C
Weight & dimensions Height: 94 mm Weight: 75 g Width: 19 mm Length: 69 mm
