Design
Stackable: No
LED indicators: PoE, Speed, Power, Link, Activity
Product colour: Black
Housing material: Metal
Rack mounting: Yes
Number of fans: 2 fan(s)
Power
AC input frequency: 50 - 60 Hz
Power consumption (max): 420 W
AC input voltage: 100 - 240 V
Power protection features: Overload, Short circuit, Over voltage
Operational conditions
Storage temperature (T-T): -10 - 70 °C
Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 204.3 mm
Weight: 4 kg
Width: 441.1 mm
Height: 44 mm
Network
Cable types supported: Cat5, Cat5e
Flow control support: Yes
10G support: No
Auto-sensing: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3x, IEEE 802.3u, IEEE 802.3at
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX
Full duplex: Yes
Performance
Noise level: 21.3 dB
Mean time between failures (MTBF): 144000 h
Packaging content
Rack mount kit: Yes
Manual: Yes
Cables included: AC
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 16
SFP module slots quantity: 2
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Store-and-forward: Yes
Packet forwarding rate (1 Gbps): 1488000 pps
Packet forwarding rate (10 Mbps): 14880 pps
Packet buffer memory: 0.5 MB
MAC address table: 8192 entries
Packet forwarding rate (100 Mbps): 148800 pps
Switching capacity: 36 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 370 W
Safety warning
Warnings: Ensure the unit is adequately ventilated during operation., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
