Design
Housing material: Metal
Wall mountable: Yes
LED indicators: Activity, Link, Power
Rack mounting: No
Product colour: Black
Power
DC input voltage: 12 V
Input current: 1 A
AC input voltage: 100 - 240 V
Power source: DC
Power consumption (typical): 12 W
Power supply included: Yes
AC input frequency: 50/60 Hz
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 400 g
Height: 28 mm
Depth: 102 mm
Width: 162 mm
Network
MAC address auto-aging supported: Yes
Full duplex: Yes
Networking standards: IEEE 802.3u, IEEE 802.3bz, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3x
Cable types supported: Cat4, Cat3, Cat5, Cat5e, Cat6a, Cat6
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Copper ethernet cabling technology: 2500BASE-T, 100BASE-TX, 1000BASE-T, 10BASE-T
Auto-sensing: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
Half duplex: Yes
Flow control support: Yes
10G support: No
Performance
Fanless: Yes
Packaging data
Package weight: 600 g
Package height: 68 mm
Package type: Box
Package width: 153 mm
Package depth: 179 mm
Packaging content
Cables included: AC
Manual: Yes
Certification: FCC, CE, RoHS, UKCA
Certificates
Compliance certificates: RoHS, CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity: 4
2.5G Ethernet (copper) ports quantity: 4
Power connector: DC-in jack
SFP+ module slots quantity: 1
Other features
Warranty period: 3 year(s)
Logistics data
Master (outer) case width: 360 mm
Master (outer) case length: 375 mm
Master (outer) case height: 328 mm
Products per master (outer) case: 20 pc(s)
Master (outer) case gross weight: 13.2 kg
Data transmission
Forwarding rate: 29.76 Mpps
Jumbo frames support: Yes
Jumbo frames: 12000
Switching capacity: 40 Gbit/s
Store-and-forward: Yes
MAC address table: 4000 entries
Packet buffer memory: 8.1 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
