Features
Internal: No
Product colour: Black
LED indicators: Yes
Housing material: Metal
Power
External power adapter: Yes
Power consumption (max): 5 W
Output voltage: 5 V
Output current: 1.2 A
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -45 - 70 °C
Weight & dimensions
Height: 26 mm
Weight: 180 g
Depth: 105 mm
Width: 70 mm
Network
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Converter input interface: 1000Base-T
Fiber ethernet cabling technology: 1000BASE‑LX
Duplex system: Full
Converter output interface: 1000Base-LX
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3u
Ethernet interface type: Gigabit Ethernet
Maximum data transfer rate: 1000 Mbit/s
Ethernet LAN data rates: 100, 1000 Mbit/s, 10
Performance
Sensitivity: -22 dBmW
Mean time between failures (MTBF): 100000 h
Tx power (min): -8 dBmW
Fiber mode structure: Single-mode
Tx power (max): -3 dBmW
Maximum transfer distance: 20000 m
Fiber cable diameters supported (core/cladding): 8.3/125, 10/125, 8.7/125, 8/125
Wavelength: 1310 nm
Packaging content
Manual: Yes
AC adapter included: Yes
Ports & interfaces
Fiber optic connector: SC
Connectivity technology: Wired
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Fiber ports quantity: 1
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: The product may contain small parts which may be hazardous to children., The product may generate heat, avoid contact with flammable materials., The product must be used in accordance with the instructions for use to avoid damage.
