Features Housing material: Metal Product colour: Silver Brand compatibility: MSA Compliant Hot-Plug support: Yes
Power Power consumption (typical): 1 W Maximum voltage: 3.3 V
Operational conditions Operating relative humidity (H-H): 10 - 85% Operating temperature (T-T): 0 - 70 °C Storage temperature (T-T): -40 - 85 °C
Weight & dimensions Width: 14 mm Height: 12 mm Depth: 57 mm Weight: 20 g
Performance SFP transceiver standard: BX-D Maximum data transfer rate: 1000 Mbit/s Interface type: mini-GBIC/SFP Networking standards: IEEE 802.3z Maximum transfer distance: 120000 m SFP transceiver type: Fiber optic Fiber optic connector: LC Fiber cable diameters supported (core/cladding): 9/125 µm Single-mode fiber (SMF) supported: Yes Fiber ethernet cabling technology: 1000BASE Tx wavelength (max): 1550 nm Rx wavelength (max): 1490 nm Tx power (min): 0 dBmW Digital Diagnostics Monitoring (DDM): Yes Wavelength-division multiplexing (WDM): Yes Tx power (max): 5 dBmW
Packaging data Package type: Box Package weight: 30 g
Packaging content Quantity per pack: 1 pc(s)
Certificates Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Logistics data Products per master (outer) case: 48 pc(s) Master (outer) case width: 200 mm Master (outer) case height: 250 mm Master (outer) case length: 310 mm Master (outer) case gross weight: 2.6 kg
