Design Fan location: Top Product colour: Black Fan diameter: 12 cm Cooling type: Active On/off switch: Yes Number of fans: 1 fan(s)
Power Maximum input current (@110V): +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V Max output current (+12V2): 22 A Max output current (+5Vsb): 3 A Combined power (+3.3V): 120 W Max output current (+3.3V): 18 A Combined power (+5V): 120 W Max output current (+12V1): 22 A Power Factor Correction (PFC) type: Active Combined power (-12V): 3.6 W Combined power (+5Vsb): 15 W Max output current (+5V): 15 A Max output current (-12V): 0.3 A Total power: 520 W AC input frequency: 47 - 63 Hz AC input voltage: 115 - 230 V
Weight & dimensions Height: 86 mm Depth: 140 mm Weight: 1.25 kg Width: 150 mm
Performance Power supply unit (PSU) form factor: ATX ATX version: 2.31 Purpose: PC Noise level: 21 dB
Packaging data Package depth: 95 mm Package width: 240 mm Package weight: 1.59 kg Package type: Box Package height: 170 mm
Ports & interfaces ATX power connector (20+4 pin): Yes CPU power connector (4+4 pin): Yes PCI Express connector: Yes Number of SATA power connectors: 4 Motherboard power connector: 20+4 pin ATX Floppy drive power connector: 1 Floppy disk drive connector: Yes Cabling type: Non-Modular Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 1
Logistics data Harmonized System (HS) code: 84733020
