Design Cooling type: Active Fan location: Top On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s) Product colour: Black
Power Max output current (+5V): 15 A Combined power (-12V): 3.6 W Max output current (+12V1): 30 A Max output current (+12V2): 30 A Max output current (+3.3V): 18 A Combined power (+5V): 103 W AC input voltage: 115 - 230 V Total power: 620 W Combined power (+5Vsb): 15 W AC input frequency: 47 - 63 Hz Combined power (+3.3V): 103 W Max output current (-12V): 0.3 A Maximum input current (@110V): +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V Power Factor Correction (PFC) type: Active Max output current (+5Vsb): 3 A
Weight & dimensions Depth: 140 mm Weight: 1.28 kg Width: 150 mm Height: 86 mm
Performance Purpose: PC Noise level: 21 dB ATX version: 2.31 Power supply unit (PSU) form factor: ATX
Packaging data Package height: 170 mm Package width: 240 mm Package type: Box Manual: Yes Package weight: 1.62 kg Package depth: 95 mm
Ports & interfaces Floppy disk drive connector: Yes PCI Express connector: Yes Cabling type: Non-Modular Peripheral (Molex) power connectors (4-pin): 4 Floppy drive power connector: 1 CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes Number of SATA power connectors: 4 PCI Express power connectors (6+2 pin): 1
Logistics data Harmonized System (HS) code: 84733020
