Technical details
Sustainability certificates: ENERGY STAR
Design
Number of fans: 1 fan(s)
Fan location: Top
Fan diameter: 12 cm
On/off switch: Yes
Product colour: Black
Power
Efficiency: 82%
Combined power (+5Vsb): 15 W
Max output current (+5V): 15 A
Maximum input current (@110V): +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V
AC input voltage: 115 - 230 V
Power protection features: Short circuit, Over voltage, Over current, Over power
Power Factor Correction (PFC) type: Active
Max output current (+12V1): 30 A
Total power: 720 W
Max output current (+3.3V): 18 A
Max output current (+5Vsb): 3 A
Combined power (-12V): 3.6 W
Max output current (-12V): 0.3 A
Max output current (+12V2): 30 A
AC input frequency: 47 - 63 Hz
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
Purpose: PC
Noise level: 21 dB
ATX version: 2.31
Power supply unit (PSU) form factor: ATX
Ports & interfaces
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Cabling type: Non-Modular
Peripheral (Molex) power connectors (4-pin): 4
Number of SATA power connectors: 4
PCI Express power connectors (6+2 pin): 2
Floppy drive power connector: 1
Logistics data
Harmonized System (HS) code: 84733020
