Design Cooling type: Active Product colour: Black Fan diameter: 14 cm Illumination: Yes Fan location: Top Number of fans: 1 fan(s)
Power Power protection features: Short circuit, Over voltage, Over power Total power: 750 W Power Factor Correction (PFC) type: Active Combined power (+3.3V): 100 W Max output current (+12V): 62 A Combined power (-12V): 3.6 W Efficiency: 87% AC input frequency: 47 - 63 Hz Combined power (+12V): 750 W Max output current (+3.3V): 20 A Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Combined power (+5V): 100 W AC input voltage: 100 - 240 V Max output current (+5Vsb): 2.5 A Max output current (-12V): 0.3 A
Weight & dimensions Weight: 1.56 kg Height: 86 mm Depth: 160 mm Width: 150 mm
Performance Purpose: PC Noise level: 35 dB Power supply unit (PSU) form factor: ATX ATX version: 2.3 80 PLUS certification: 80 PLUS Gold
Packaging data Package width: 270 mm Package depth: 95 mm Package type: Box Manual: Yes Package weight: 2.25 kg Package height: 215 mm
Packaging content Cables included: AC
Ports & interfaces SATA power cable length: 600, 750, 450 CPU power connector (4+4 pin): Yes ATX power connector (20+4 pin): Yes Motherboard power connector: 20+4 pin ATX Floppy disk drive connector: Yes PCI Express power connectors (6+2 pin): 4 Motherboard power cable length: 55 cm Floppy drive power connector: 1 Number of SATA power connectors: 8 CPU power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 3 PCI Express connector: Yes Cabling type: Semi-Modular PCI Express power cable length: 70 cm
Other features Illumination colour: Red, Green, Blue Screws included: Yes
Logistics data Harmonized System (HS) code: 84733020
