Design On/off switch: Yes Fan location: Side LED indicators: Yes Product colour: Grey Fan diameter: 4 cm Number of fans: 4 fan(s)
Power Max output current (+5V): 30 A AC input frequency: 50 - 60 Hz Combined power (+5V): 200 W Max output current (+3.3V): 30 A Max output current (+12V): 58 A Power Factor Correction (PFC) type: Active Power protection features: Overheating, Over power, Over current, Short circuit, Over voltage Total power: 700 W Combined power (+3.3V): 200 W Efficiency: 92% Max output current (-12V): 1 A Max output current (+5Vsb): 3 A AC input voltage: 115 - 230 V
Weight & dimensions Width: 150 mm Depth: 190 mm Weight: 3.69 kg Height: 84 mm
Performance Power supply unit (PSU) form factor: PS/2 Mean time between failures (MTBF): 100000 h Purpose: Server
Packaging data Package weight: 4.09 kg
Packaging content Cables included: AC
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 6 ATX power connector (20+4 pin): Yes Floppy disk drive connector: Yes Floppy drive power connector: 1 Number of SATA power connectors: 2 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes
Logistics data Harmonized System (HS) code: 84733020
