Design Cooling type: Active On/off switch: Yes Fan location: Top Number of fans: 1 fan(s) Product colour: Black
Power Input current: 10/5 A Power protection features: Overheating, No load operation, Under voltage, Over current, Short circuit, Over voltage, Over power Combined power (+5Vsb): 15 W AC input voltage: 100 - 240 V Max output current (+5V): 20 A Combined power (+3.3V): 100 W Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (+5Vsb): 3 A Combined power (-12V): 4.8 W Max output current (+12V): 70.8 A Max output current (-12V): 0.3 A AC input frequency: 50/60 Hz Power Factor Correction (PFC) type: Active Combined power (+12V): 850 W Total power: 850 W
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage relative humidity (H-H): 0 - 95% Operating relative humidity (H-H): 0 - 90% Storage temperature (T-T): -20 - 90 °C
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm Weight: 2.32 kg
Performance Purpose: PC 80 PLUS certification: 80 PLUS Bronze ATX version: 3.1 Power supply unit (PSU) form factor: ATX
Packaging data Package type: Box Package weight: 2.76 kg
Ports & interfaces Number of EPS connectors: 2 ATX power connector (20+4 pin): Yes Floppy disk drive connector: Yes Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 6 Floppy drive power connector: 1 Motherboard power connector: 20+4 pin ATX EPS power connector (4+4 pin): Yes
