Design On/off switch: Yes Number of fans: 1 fan(s) Fan diameter: 12 cm Fan location: Side Cooling type: Active Product colour: Silver
Power Power protection features: Over current, Short circuit, Over voltage Max output current (+12V1): 15 A AC input frequency: 50 - 60 Hz Max output current (+3.3V): 15 A Combined power (+5V): 103 W Input current: 8 A AC input voltage: 115 - 230 V Max output current (+5V): 12 A Total power: 350 W Max output current (+12V2): 15 A Maximum input current (@110V): +3.3V,+5Vsb,+12V1,-12V,+12V2,+5V Max output current (-12V): 0.3 A Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 103 W Power Factor Correction (PFC) type: Active
Weight & dimensions Depth: 140 mm Width: 150 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Bronze Purpose: PC ATX version: 2.3 Noise level: 25 dB Power supply unit (PSU) form factor: ATX
Certificates Compliance certificates: RoHS
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes ATX power connector (20+4 pin): Yes Number of SATA power connectors: 3 PCI Express power connectors (6+2 pin): 1
Logistics data Harmonized System (HS) code: 84733020
