Design Fan location: Side Number of fans: 1 fan(s) Fan diameter: 4 cm Product colour: Grey
Power Combined power (+5Vsb): 10 W Power protection features: Over power, Short circuit, Over current AC input voltage: 110 - 240 V AC input frequency: 50 - 60 Hz Total power: 250 W Combined power (-12V): 3.6 W Max output current (+5V): 18 A Efficiency: 86% Max output current (+3.3V): 16 A Combined power (+12V): 240 W Max output current (-12V): 0.3 A Max output current (+5Vsb): 2 A Max output current (+12V): 20 A Combined power (+3.3V): 100 W Power Factor Correction (PFC) type: Active
Weight & dimensions Weight: 760 g Depth: 150 mm Width: 82 mm Height: 41 mm
Packaging data Manual: Yes Package weight: 1.01 kg
Ports & interfaces SATA power cable length: 450 Cabling type: Non-Modular Motherboard power connector: 20+4 pin ATX PCI Express connector: Yes ATX power connector (20+4 pin): Yes PCI Express power cable length: 45 cm Motherboard power cable length: 45 cm Peripheral (Molex) power connectors (4-pin): 2 Number of SATA power connectors: 2 PCI Express power connectors (6+2 pin): 1
Logistics data Harmonized System (HS) code: 84733020 Products per master (outer) case: 18 pc(s)
