Design Number of fans: 1 fan(s) Product colour: Silver Cooling type: Active
Power Input current: 8 A AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Max output current (-12V): 0.3 A Combined power (+5Vsb): 12.5 W Max output current (+5V): 10 A Combined power (+12V): 348 W Combined power (+5V): 60 W Max output current (+3.3V): 10 A Power protection features: Under voltage, Over current, Short circuit, Over voltage Combined power (-12V): 3.6 W Max output current (+5Vsb): 2.5 A Total power: 350 W Max output current (+12V): 29 A Combined power (+3.3V): 60 W Efficiency: 91.9% Power Factor Correction (PFC) type: Active
Operational conditions Operating relative humidity (H-H): 20 - 80% Storage relative humidity (H-H): 10 - 50% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -20 - 80 °C
Weight & dimensions Width: 150 mm Depth: 81.5 mm Weight: 850 g Height: 40.5 mm
Performance 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 50000 h Purpose: Server Power supply unit (PSU) form factor: Flex ATX
Packaging data Package weight: 910 g
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 Number of SATA power connectors: 3 EPS power connector (4+4 pin): Yes ATX power connector (20+4 pin): Yes Motherboard power connector: 20+4 pin ATX
