Design Fan location: Top Cooling type: Active On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s) Product colour: Black
Power Power protection features: Short circuit, Over voltage, Over power Total power: 550 W Combined power (+5V): 120 W Max output current (+3.3V): 20 A Combined power (+5Vsb): 12.5 W AC input voltage: 100 - 240 V Input current: 10 A Max output current (+5V): 18 A Max output current (+5Vsb): 2.2 A Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W Combined power (+3.3V): 120 W Max output current (+12V): 40 A Efficiency: 85% Combined power (+12V): 420 W AC input frequency: 50 - 60 Hz Power Factor Correction (PFC) type: Active
Weight & dimensions Weight: 1.14 kg Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Noise level: 35 dB Purpose: PC ATX version: 2.4 Power supply unit (PSU) form factor: ATX
Packaging data Package height: 175 mm Package type: Box Package weight: 1.49 kg Package width: 230 mm Package depth: 95 mm
Ports & interfaces PCI Express power connectors (6-pin): 1 Floppy disk drive connector: Yes PCI Express connector: Yes Motherboard power cable length: 50 cm CPU power cable length: 50 cm PCI Express power cable length: 50 cm CPU power connector (4+4 pin): Yes Peripheral (Molex) power connectors (4-pin): 4 Number of SATA power connectors: 4 Motherboard power connector: 20+4 pin ATX Floppy drive power connector: 1 ATX power connector (20+4 pin): Yes
Logistics data Harmonized System (HS) code: 84733020
