Design Fan location: Top Product colour: Black On/off switch: Yes Fan diameter: 12 cm Cooling type: Active
Power Max output current (+5Vsb): 2.2 A AC input frequency: 50 - 60 Hz Input current: 10 A Max output current (+5V): 18 A Efficiency: 85% Combined power (+5Vsb): 11 W Max output current (+12V): 50 A Max output current (+3.3V): 20 A Max output current (-12V): 0.3 A Combined power (+5V): 120 W AC input voltage: 100 - 240 V Total power: 650 W Power protection features: Over power, Short circuit, Over voltage Combined power (+3.3V): 120 W Combined power (-12V): 3.6 W Combined power (+12V): 520 W
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm Weight: 1.14 kg
Performance Power supply unit (PSU) form factor: ATX Noise level: 35 dB Purpose: PC ATX version: 2.4
Packaging data Package weight: 1.49 kg Package height: 175 mm Package type: Box Package depth: 95 mm Package width: 230 mm
Packaging content Cables included: AC
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 4 Motherboard power cable length: 50 cm Number of SATA power connectors: 4 ATX power connector (20+4 pin): Yes CPU power cable length: 50 cm PCI Express power connectors (6+2 pin): 1 CPU power connector (4+4 pin): Yes PCI Express power cable length: 50 cm Floppy disk drive connector: Yes PCI Express connector: Yes Floppy drive power connector: 1 Motherboard power connector: 20+4 pin ATX
Logistics data Harmonized System (HS) code: 84733020
