Design Product colour: Grey Number of fans: 1 fan(s) Fan diameter: 8 cm
Power Power protection features: Short circuit, Over voltage, Over current Max output current (+12V1): 11 A Combined power (+5Vsb): 12.5 W Input current: 4 - 8 A AC input voltage: 110 - 240 V Max output current (+5V): 8 A Max output current (+12V2): 11 A Max output current (+5Vsb): 2.5 A Max output current (+3.3V): 8 A Combined power (-12V): 3.6 W AC input frequency: 50 - 60 Hz Max output current (-12V): 0.3 A Total power: 300 W Combined power (+5V): 40 W Combined power (+12V): 132 W Combined power (+3.3V): 26.4 W Power Factor Correction (PFC) type: Active
Weight & dimensions Width: 125 mm Depth: 100 mm Weight: 810 g Height: 63.5 mm
Performance Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS
Ports & interfaces CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 1 Number of SATA power connectors: 3 Peripheral (Molex) power connectors (4-pin): 2 Motherboard power connector: 20+4 pin ATX Floppy drive power connector: 1
Logistics data Harmonized System (HS) code: 84733020
