Design
Mounting type: Ceiling/wall
Weatherproof: Yes
Form factor: Dome
LED indicators: Yes
Product colour: Assorted colours
International Protection (IP) code: IP67
Housing material: Metal
IK code: IK10
Fog proof: Yes
Power
Power consumption (Power over Ethernet (PoE)): 7.7 W
DC output voltage: 12
Power source type: DC, PoE
Power consumption (max): 6.4 W
Power consumption (typical): 3.2 W
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Behavior analysis: Intrusion detection, Line crossing detection
Web browser: Yes
Web-based management: Yes
Weight & dimensions
Weight: 500 g
Diameter: 12.2 cm
Height: 94 mm
Network
Streaming method: Unicast, Multicast
Number of users: 20 user(s)
Bluetooth: No
Networking standards: IEEE 802.1x
Wi-Fi: No
Ethernet LAN: Yes
System requirements
Mobile operating systems supported: Android, iOS
Performance
Dynamic range: 120 dB
Placement supported: Indoor & outdoor
Alarm input/output: Yes
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Packaging data
Package weight: 770 g
Packaging content
Number of cameras: 1
Storage
ROM capacity: 128 MB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 256 GB
Built-in HDD: No
Internal memory: 512 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera tilt control: No
Lens viewing angle, vertical: 75°
Lens viewing angle, diagonal: 175°
Lens viewing angle, horizontal: 170°
Tilt angle range: 0 - 80°
White balance: Manual, Outdoor, Auto, Natural, Custom modes, Street lamp
Adjustment shutter speed: Auto/Manual
Minimum illumination: 0.0005 lx
Pan range: 0 - 355°
Camera shutter type: Electronic
Angle of rotation: 355°
Camera shutter speed: 1/3 s–1/100,000
Image sensor
Number of sensors: 1
Number of effective pixels (H x V): 2880 x 1620 pixels
Progressive scan: Yes
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Gain control type: Auto/Manual
Maximum resolution: 2880 x 1620 pixels
Video formats supported: H.264+, H.265+
Noise reduction: Yes
Highlight Compensation (HLC): Yes
Back Light Compensation (BLC): Yes
Video compression formats: M-JPEG, H.265, H.264B, H.264
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction technology: 3D noise reduction
Total megapixels: 4 MP
Region of Interest (ROI) encoding: Yes
Night vision
Night vision: Yes
Lens system
Closest focusing distance: 0.6 m
Number of lenses: 1
Maximum aperture number: 2
Fixed focal length: 2.1 mm
