Design
Product colour: White
Mounting type: Wall/ceiling
Housing material: Metal, Plastic
Form factor: Tube/dome
International Protection (IP) code: IP67
Power
Power source type: DC, PoE
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 3.5 W
Power consumption (max): 4.5 W
Power consumption (typical): 2.5 W
Operational conditions
Storage temperature (T-T): -40 - 55 °C
Operating temperature (T-T): -40 - 55 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web browser: Yes
Web-based management: Yes
Dedicated application: DMSS (Android, iOS)
Weight & dimensions
Weight: 350 g
Height: 85.6 mm
Product diameter: 94 mm
Network
4G LTE: No
Bluetooth: No
Networking standards: IEEE 802.3af
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
Wi-Fi: No
System requirements
Mobile operating systems supported: iOS, Android
Performance
Placement supported: Outdoor
Connectivity technology: Wired
Signal-to-Noise Ratio (SNR): 56 dB
Type: IP security camera
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Two-way talk: N
Audio codecs: PCM, G.711a G.711Mu, G.726
Built-in loudspeaker: No
Storage
ROM capacity: 128 MB
RAM capacity: 256 MB
Camera
Vertical rotation angle: 0 - 78°
Viewing angle, diagonal: 132°
Horizontal rotation angle: 0 - 360°
Minimum illumination: 0.008 lx
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 - 1/100000 s
Motion detection : Yes
Lens viewing angle, vertical: 58°
People detection : Yes
Lens viewing angle, horizontal: 110°
Image sensor
Sensor type: HD CMOS
Number of sensors: 1
Progressive scan: Yes
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Total megapixels: 8 MP
Video compression formats: M-JPEG, H.264H, H.264+, H.265+, H.264, H.264B, H.265
Video streaming: Yes
Maximum resolution: 3840 x 2160 pixels
Frame rate: 20 / 25 / 30 fps
Night vision
Night vision: Yes
Night vision distance: 30 m
LED type: IR / White light LED
Number of illumination LEDs: 1 / 1
Lens system
Lens type: Fixed focal length lens
Number of lenses: 1
Maximum aperture number: 1.6
Focal length range: 2.8 mm
Closest focusing distance: 1.5 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
