Design
Mounting type: Ceiling
Product colour: White
Housing material: Metal, Plastic
International Protection (IP) code: IP67
Form factor: Dome
Power
Power consumption (Power over Ethernet (PoE)): 5.9 W
Power source type: DC, PoE
DC output voltage: 12
Power consumption (max): 5 W
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 55 °C
Management features
Web browser: Yes
Web-based management: Yes
Weight & dimensions
Diameter: 12.2 cm
Weight: 480 g
Height: 99.1 mm
Network
Number of users: 20 user(s)
Quality of Service (QoS) support: Yes
Bluetooth: No
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.3af
Wi-Fi: No
System requirements
Mobile operating systems supported: iOS, Android
Certification: LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B 2023-04-10
Performance
Placement supported: External / Internal
Signal-to-Noise Ratio (SNR): 56 dB
Wide Dynamic Range (WDR): 120 dB
Connectivity technology: Wired
Type: IP security camera
Packaging content
Number of cameras: 1
Audio
Audio formats supported: G.711a, G.711Mu, G.726, PCM
Built-in microphone: Yes
Storage
Built-in HDD: No
Internal memory: 256 MB
ROM capacity: 128 MB
Camera
Camera shutter speed: 1/3 - 1/100000 s
White balance: Natural, Manual, Outdoor, Auto, Street lamp
Pan range: 0 - 360°
Tilt angle range: 0 - 78°
Adjustment shutter speed: Auto/Manual
Minimum illumination: 0.008 lx
Lens viewing angle, horizontal: 111°
Lens viewing angle, diagonal: 132°
Lens viewing angle, vertical: 58°
Image sensor
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Video streaming: Yes
Frame rate: 30 fps
Video compression formats: M-JPEG, H.265+, H.265, H.264H, H.264+, H.264, H.264B
Region of Interest (ROI) encoding: Yes
Noise reduction technology: 3D noise reduction
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC): Yes
Supported graphics resolutions: 2880 x 1620, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 3072 x 1728, 352 x 240, 2304 x 1296, 640 x 480 (VGA), 3072 x 2048, 3840 x 2160, 704 x 480, 2688 x 1520, 352 x 288, 1280 x 720 (HD 720), 704 x 576, 1280 x 960
Total megapixels: 8 MP
Noise reduction: Yes
Maximum resolution: 3840 x 2160 pixels
Bit rate: H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps
Gain control type: Auto/Manual
Back Light Compensation (BLC): Yes
Mirror function: Yes
Night vision
Night vision: Yes
Night vision distance: 30 m
Number of illumination LEDs: 2
LED type: IR / White light LED
Lens system
Number of lenses: 1
Focal length range: 2.8 mm
Maximum aperture number: 1.6
Lens type: Fixed focal length lens
Closest focusing distance: 1.5 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
