Design
Housing material: Metal, Plastic
International Protection (IP) code: IP67
Product colour: White
Form factor: Tube/dome
Mounting type: Wall/ceiling
Power
Power source type: DC, PoE
Power consumption (max): 6.1 W
Power consumption (typical): 2 W
Power consumption (Power over Ethernet (PoE)): 7.2 W
DC output voltage: 12
Operational conditions
Storage temperature (T-T): -40 - 55 °C
Operating temperature (T-T): -40 - 55 °C
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 720 g
Depth: 238.5 mm
Width: 75.8 mm
Height: 71.6 mm
Network
Wi-Fi: No
Networking standards: IEEE 802.3af
Bluetooth: No
4G LTE: No
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
System requirements
Mobile operating systems supported: iOS, Android
Performance
Signal-to-Noise Ratio (SNR): 56 dB
Placement supported: Outdoor
Wide Dynamic Range (WDR): 120 dB
Type: IP security camera
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Audio
Built-in loudspeaker: No
Built-in microphone: Yes
Two-way talk: N
Audio codecs: G.711a, G.711Mu, G.726, PCM
Storage
ROM capacity: 128 MB
RAM capacity: 128 MB
Camera
Lens viewing angle, horizontal: 84°
Lens viewing angle, vertical: 42°
Motion detection : Yes
People detection : Yes
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0.006 lx
Vertical rotation angle: 0 - 90°
Horizontal rotation angle: 0 - 360°
Viewing angle, diagonal: 101°
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
Number of sensors: 1
Sensor type: HD CMOS
Video
Maximum resolution: 2688 x 1520 pixels
Video compression formats: M-JPEG, H.265, H.264+, H.265+, H.264, H.264H, H.264B
Total megapixels: 4 MP
Frame rate: 20 fps
Video streaming: Yes
Night vision
Night vision: Yes
LED type: IR / White light LED
Night vision distance: 60 / 50 m
Number of illumination LEDs: 2 / 2
Lens system
Closest focusing distance: 1.7 m
Maximum aperture number: 1.6
Focal length range: 3.6 mm
Number of lenses: 1
Lens type: Fixed focal length lens
