Design
Product colour: White
IK code: IK10
Protection features: Vibration proof
Form factor: Bullet
International Protection (IP) code: IP67
Housing material: Plastic, Metal
Mounting type: Ceiling/wall
Power
Power source type: DC
Power consumption (max): 6.5 W
DC output voltage: 12
Security
Detection distance: 30 m
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -10 - 50 °C
Storage temperature (T-T): -10 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Network
Ethernet interface type: Fast Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth: No
Networking standards: IEEE 802.11g, IEEE 802.11h, IEEE 802.11b
Streaming method: Multicast, Unicast
Number of users: 20 user(s)
System requirements
Mobile operating systems supported: iOS, Android
Performance
Connectivity technology: Wired & Wireless
Type: IP security camera
PTZ control: Yes
Auto pan mode: Yes
Placement supported: Indoor & outdoor
Day/night mode: Yes
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 50 dB
Storage
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Built-in HDD: No
Maximum memory card size: 128 GB
Camera
Minimum illumination: 0.1 lx
White balance: Auto, Outdoor, Manual, Natural
Camera pan control: Yes
Camera tilt control: Yes
Image sensor
Effective sensor resolution (thermal module): 2688 x 1520 pixels
Optical sensor size: 25.4 / 3 mm (1 / 3")
Number of sensors: 1
Progressive scan: Yes
Sensor type: CMOS
Video
Back Light Compensation (BLC): Yes
Supported graphics resolutions: 2688 x 1520, 2304 x 1296
Video formats supported: H.265, H.264
Frame rate: 30 fps
Digital Wide Dynamic Range (DWDR): Yes
Noise reduction technology: 3D noise reduction
Noise reduction: Yes
Supported video modes: 720p, 1080p
Video compression formats: MPEG
Video streaming: Yes
Smart IR: Yes
Night vision
Number of illumination LEDs: 24
Lens system
Fixed focal length: 3.6 mm
Aperture number (thermal module): 2
