Processor
Built-in processor: Yes
Certification: CE EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 CE LVD: EN 62368-1:2014 2023-09-26
Features
Rack capacity: 1U
LED indicators: Yes
Product colour: White
Rack mounting: Yes
Power
Output voltage: 12 V
Output current: 1.5 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 93%
Weight & dimensions
Weight: 450 g
Package width: 96 mm
Width: 204.6 mm
Package depth: 364 mm
Depth: 206.4 mm
Height: 45.6 mm
Package height: 261 mm
Package weight: 1.05 kg
System requirements
Mobile operating systems supported: iOS, Android
Browser supported: Chrome; IE 9 or later; Firefox
Performance
Video codecs: Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Operating system installed: Embedded LINUX
Playback modes: Pause, Play, Stop
Video input channels: 4 channels
Video recording modes: 720p, 1024p, 1080p, 2160p
Input bandwidth: 80 Mbit/s
Recording modes: Manual
Output bandwidth: 60 Mbit/s
Audio codecs: PCM; G711A; G711U; G726
Ports & interfaces
HDMI output: Yes
Audio RCA outputs: 1
DC-in jack: Yes
VGA (D-Sub) output ports: 1
Ethernet LAN data rates: 10, 100
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
Audio RCA inputs: 1
HDMI ports quantity: 1
Hard drive
Maximum storage capacity: 20 TB
HDD interface: SATA
Number of HDDs installed: 1
Safety warning
Warnings: The product must be disposed of properly in accordance with local regulations for the disposal of electronics., Do not expose the device to moisture or extreme temperatures.
