Processor
Processor cores: 4
Compatible products: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec
Certification: CE, FCC, UL, EN55032, EN55024, EN50130-4, EN60950-1, Part 15 Subpart B, ANSI C63.4-2014, UL60950-1+CAN/CSA C22.2 No.60950-1
Features
Product colour: Black
Rack mounting: Yes
Rack capacity: 1U
Brand compatibility: Any brand
Power
Output voltage: 12 V
Power consumption (typical): 6.3 W
Output current: 2 A
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 90%
Storage temperature (T-T): -20 - 70 °C
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Height: 47.6 mm
Weight: 800 g
Package weight: 1.6 kg
Depth: 224.9 mm
Width: 260 mm
System requirements
Mobile operating systems supported: iOS, Android
Supported resolutions: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
Performance
Two-way talk: Yes
Video loss detection: Yes
Number of motion detection zones: 396
On Screen Display (OSD): Yes
People counting: Yes
Recording time: 120 min
Video formats supported: H.265, H.264
Recording modes: Manual, Schedule, Stop
PTZ control: Yes
Bit rate: 20000 Kbit/s
Multi-screen: Yes
Snapshot: Yes
Number of users: 128 user(s)
Video motion detection: Yes
Throughput data rate: 80 Mbit/s
Maximum resolution: 3840 x 2160 pixels
Video input channels: 4 channels
Playback controls: Yes
Wireless LAN features
Wi-Fi: No
Ports & interfaces
VGA (D-Sub) output ports: 1
HDMI ports quantity: 1
Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP
SATA revision: 3.0
HDMI output: Yes
Audio RCA outputs: 1
Power over Ethernet (PoE): No
Internal SATA ports quantity: 1
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Audio RCA inputs: 1
Hard drive
HDD interface: SATA III
Number of HDDs supported: 1
Maximum storage capacity: 6 TB
