Processor
Built-in processor: Yes
Certification: CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Features
Product colour: Black
Rack mounting: Yes
Rack capacity: 1U
Power
Output voltage: 12DC
Output current: 2 A
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 93%
Weight & dimensions
Package depth: 89 mm
Height: 47.6 mm
Package weight: 1.38 kg
Package height: 314 mm
Package width: 334 mm
Width: 260 mm
Weight: 810 g
Depth: 232.5 mm
System requirements
Mobile operating systems supported: iOS, Android
Browser supported: Chrome; IE; Safari; Edge; Firefox
Supported resolutions: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Video formats supported: H.265, H.265+, H.264, MJPG
Maximum resolution: 3840 x 2160 pixels
Multi-screen: Yes
Video loss detection: Yes
Operating system installed: Embedded LINUX
Audio codecs: G.711a; G.711u; PCM; G726
Maximum frame rate: 30 fps
Video motion detection: Yes
Input bandwidth: 80 Mbit/s
Number of simultaneously playbacked channels: 8 channels
Face detection: Yes
Snapshot: Yes
Audio formats supported: G.726, PCM, G.711 A-law, G.711 μ-law
Output bandwidth: 60 Mbit/s
Video codecs: Smart H.265+; H.265; Smart H.264+; H.264
Video recording modes: 1080p, 720p, 2160p
People counting: Yes
Display
Built-in display: No
Ports & interfaces
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Power over Ethernet (PoE): Yes
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Audio RCA outputs: 1
Audio output: 1-channel RCA
Audio RCA inputs: 1
VGA (D-Sub) output ports: 1
Hard drive
HDD interface: SATA
Maximum storage capacity: 20 TB
Number of HDDs supported: 1
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
