Power
Power: 10 W
AC input frequency: 50/60 Hz
Power consumption (typical): 10 W
AC input voltage: 100 - 240 V
Weight & dimensions
Weight: 2.47 kg
Height: 53 mm
Package width: 451 mm
Package height: 425 mm
Package weight: 3.68 kg
Package depth: 147 mm
Depth: 327 mm
Width: 375 mm
Supported resolutions: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Performance
Maximum resolution: 3840 x 2160 pixels
Video formats supported: H.264+, H.265, H.265+, H.264
Multi-screen: Yes
Audio formats supported: G.711 μ-law, G.726, PCM, G.711 A-law
Alarm output channels: 2
Alarm input channels: 4
Video input channels: 16 channels
Face detection: Yes
Ports & interfaces
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
Internal SATA ports quantity: 2
Audio RCA inputs: 1
Audio RCA outputs: 1
VGA (D-Sub) output ports: 1
Hard drive
HDD interface: SATA
Number of HDDs supported: 2
Maximum storage capacity: 20 TB
Safety warning
Warnings: Do not expose the device to moisture or extreme temperatures., The product must be disposed of properly in accordance with local regulations for the disposal of electronics., The appliance should be installed by a qualified professional.
